The Dodge Magnum 3.5L V6, produced from 2003 to 2008, represents a unique offering in the American automotive landscape. Positioned as a mid-range trim within the Magnum lineup, it slotted between the base 2.7L V6 and the performance-oriented SRT8 models. Built on the rear-wheel-drive LX platform shared with other Dodge and Chrysler vehicles, the Magnum aimed to revive the American station wagon, blending practicality with a muscular aesthetic. This variant, powered by the EGG engine code, was a popular choice for buyers seeking a balance of power, space, and relative fuel efficiency.
Technical Specifications
| Brand | Dodge |
| Model | Magnum |
| Type (Engine) | 3.5 i V6 24V (254 Hp) |
| Start of production | 2003 |
| End of production | 2008 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate) |
| Seats | 5 |
| Doors | 5 |
| Fuel consumption (urban) | 13.8 l/100 km (17 US mpg, 20.5 UK mpg) |
| Fuel consumption (extra urban) | 9.4 l/100 km (25 US mpg, 30.1 UK mpg) |
| Fuel consumption (combined) | 11.8 l/100 km (19.9 US mpg, 23.9 UK mpg) |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 8.5 sec |
| Acceleration 0 – 62 mph | 8.5 sec |
| Acceleration 0 – 60 mph | 8.1 sec |
| Maximum speed | 210 km/h (130.49 mph) |
| Weight-to-power ratio | 7 kg/Hp, 143.3 Hp/tonne |
| Weight-to-torque ratio | 5.2 kg/Nm, 191.3 Nm/tonne |
| Power | 254 Hp @ 6400 rpm |
| Power per litre | 72.2 Hp/l |
| Torque | 339 Nm @ 4000 rpm (250.03 lb.-ft. @ 4000 rpm) |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | EGG |
| Engine displacement | 3518 cm3 (214.68 cu. in.) |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 96 mm (3.78 in.) |
| Piston Stroke | 81 mm (3.19 in.) |
| Compression ratio | 9.9:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Engine oil capacity | 5.7 l (6.02 US qt | 5.02 UK qt) |
| Coolant capacity | 10 l (10.57 US qt | 8.8 UK qt) |
| Kerb Weight | 1772 kg (3906.59 lbs.) |
| Trunk (boot) space – minimum | 770 l (27.19 cu. ft.) |
| Fuel tank capacity | 68 l (17.96 US gal | 14.96 UK gal) |
| Length | 5020 mm (197.64 in.) |
| Width | 1880 mm (74.02 in.) |
| Height | 1505 mm (59.25 in.) |
| Wheelbase | 3050 mm (120.08 in.) |
| Front track | 1600 mm (62.99 in.) |
| Rear track | 1600 mm (62.99 in.) |
| Drivetrain Architecture | Rear wheel drive |
| Number of gears | 4 |
| Gearbox type | Automatic transmission |
| Front suspension | Double wishbone |
| Rear suspension | Wishbone |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 225/60 R18 |
Powertrain & Engine Architecture
The heart of the Dodge Magnum 3.5L is the EGG engine, a 3.5-liter (3518 cc) naturally aspirated V6. This engine utilizes a 60-degree V-angle and features a cast iron block with aluminum cylinder heads. It employs a multi-port fuel injection system, delivering fuel directly to each intake port. The engine is equipped with four valves per cylinder (24V) operated by dual overhead camshafts. The 42RFE four-speed automatic transmission was the sole transmission option for this trim. This transmission is known for its durability and smooth shifting characteristics, though it lacks the efficiency of more modern transmissions. The engine’s design prioritized smooth power delivery over outright performance, making it well-suited for everyday driving and towing.
Driving Characteristics
The 3.5L V6-equipped Magnum offered a comfortable and capable driving experience. While not as quick as the SRT8, it provided adequate acceleration for most situations, achieving 0-60 mph in around 8.1 seconds. The automatic transmission, while not offering manual control, provided smooth and predictable gear changes. The rear-wheel-drive layout contributed to a balanced feel, although it could be prone to oversteer in challenging conditions. The Magnum’s relatively long wheelbase and well-tuned suspension absorbed bumps effectively, providing a comfortable ride. Compared to the manual transmission versions, the automatic sacrificed some responsiveness, but gained ease of use, particularly in city driving. The 3.5L engine’s torque curve was relatively flat, providing usable power across a wide range of RPMs.
Equipment & Trim Levels
The 3.5L Magnum typically came standard with features such as air conditioning, power windows and locks, a CD player, and cloth upholstery. Optional extras included leather seats, a sunroof, premium sound system, and alloy wheels. The interior design was functional and straightforward, prioritizing practicality over luxury. The Magnum’s spacious interior and large cargo area were key selling points, making it a versatile vehicle for families and those needing to transport large items. The SXT trim level was a common configuration for the 3.5L engine, adding features like upgraded interior trim and exterior styling elements.
Chassis & Braking
The Magnum’s chassis featured a double wishbone front suspension and a multi-link rear suspension, providing a comfortable ride and decent handling. The braking system consisted of ventilated discs at the front and solid discs at the rear. Anti-lock brakes (ABS) were standard equipment. The Magnum’s weight, around 3900 pounds, contributed to its stable feel on the road. The steering was responsive and provided good feedback, although it lacked the precision of some European sports wagons. Stabilizer bars were included front and rear to reduce body roll during cornering.
Market Reception & Comparison
The Dodge Magnum 3.5L V6 was generally well-received by critics as a practical and stylish alternative to traditional SUVs. It offered a good balance of performance, space, and fuel economy, although its fuel consumption of around 19.9 US mpg combined was not exceptional. Compared to the higher-output SRT8, the 3.5L offered a more affordable price point and better fuel efficiency, but lacked the SRT8’s exhilarating performance. Compared to the base 2.7L V6, the 3.5L provided a significant power boost and a more refined driving experience. Reliability was generally good, with the 42RFE transmission proving to be particularly durable.
Legacy
The Dodge Magnum, despite its relatively short production run, has gained a cult following among enthusiasts. The 3.5L V6 powertrain, while not the most powerful option, has proven to be reliable and relatively easy to maintain. Used examples are readily available and typically offer good value for money. The Magnum’s unique styling and spacious interior continue to appeal to buyers looking for a distinctive and practical vehicle. The engine, while not known for exceptional fuel economy, remains a capable and dependable powerplant, making the 3.5L Magnum a viable option for those seeking a classic American station wagon.
