The Fiat Palio Weekend 1.6 i ED (87 Hp), produced between 1997 and 2002, represents a practical and affordable station wagon offering within the broader Fiat Palio range. Part of the 178 project series, the Weekend variant aimed to provide increased cargo capacity and versatility compared to the standard Palio hatchback, catering to families and those requiring a more spacious vehicle. Positioned as a mid-range offering within the Palio Weekend lineup, the 1.6 i ED trim balanced performance with fuel efficiency and a reasonable price point, making it a popular choice in several South American and European markets. It was a key model in Fiat’s strategy to offer a diverse range of vehicles appealing to a wide customer base.
Technical Specifications
| Brand | Fiat |
| Model | Palio |
| Generation | Palio Weekend (178) |
| Type (Engine) | 1.6 i ED (87 Hp) |
| Start of production | 1997 |
| End of production | 2002 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate) |
| Seats | 5 |
| Doors | 5 |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 11.6 sec |
| Acceleration 0 – 62 mph | 11.6 sec |
| Acceleration 0 – 60 mph | 11 sec |
| Maximum speed | 175 km/h (108.74 mph) |
| Weight-to-power ratio | 12.4 kg/Hp, 80.6 Hp/tonne |
| Weight-to-torque ratio | 8.6 kg/Nm, 115.7 Nm/tonne |
| Power | 87 Hp @ 5750 rpm |
| Power per litre | 55 Hp/l |
| Torque | 125 Nm @ 3000 rpm (92.2 lb.-ft. @ 3000 rpm) |
| Engine layout | Front, Transverse |
| Engine displacement | 1581 cm3 (96.48 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 86.4 mm (3.4 in.) |
| Piston Stroke | 67.4 mm (2.65 in.) |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Kerb Weight | 1080 kg (2380.99 lbs.) |
| Max. weight | 1675 kg (3692.74 lbs.) |
| Max load | 595 kg (1311.75 lbs.) |
| Trunk (boot) space – minimum | 460 l (16.24 cu. ft.) |
| Trunk (boot) space – maximum | 1540 l (54.38 cu. ft.) |
| Fuel tank capacity | 51 l (13.47 US gal | 11.22 UK gal) |
| Length | 4130 mm (162.6 in.) |
| Width | 1626 mm (64.02 in.) |
| Height | 1475 mm (58.07 in.) |
| Wheelbase | 2423 mm (95.39 in.) |
| Front track | 1388 mm (54.65 in.) |
| Rear (Back) track | 1385 mm (54.53 in.) |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Spring Strut |
| Rear suspension | Trailing arm |
| Front brakes | Disc |
| Rear brakes | Drum |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 175/65 R14 T |
Powertrain & Engine Architecture
The heart of the Palio Weekend 1.6 i ED is the Fiat 1.6-liter inline-four cylinder engine, typically identified by engine codes such as the 178C3.000. This engine is a naturally aspirated unit employing a multi-port fuel injection system. The engine features a single overhead camshaft (SOHC) design with two valves per cylinder. This configuration prioritized simplicity and reliability over outright performance. The 1.6-liter engine produced 87 horsepower at 5750 rpm and 125 Nm (92.2 lb-ft) of torque at 3000 rpm. The engine’s design focused on providing adequate power for everyday driving conditions, rather than sporty acceleration. It was paired with a five-speed manual transmission, offering a balance between fuel economy and driver control. The transmission was a standard configuration for the Palio range, known for its relatively smooth operation and durability.
Driving Characteristics
The Palio Weekend 1.6 i ED offered a comfortable, if not particularly exciting, driving experience. The 87 hp engine provided sufficient power for typical urban and highway driving, but acceleration was modest. The 0-60 mph time of around 11 seconds reflects this. The five-speed manual transmission allowed drivers to keep the engine in its optimal power band, but the lack of a sixth gear meant that highway cruising could be somewhat noisy. Compared to the more powerful Palio Weekend 1.7 versions, the 1.6 i ED felt noticeably less responsive. However, it offered better fuel economy and a more forgiving driving experience. The suspension, tuned for comfort, absorbed bumps reasonably well, but the car wasn’t particularly adept at handling sharp corners. The steering was light and easy to use, making it well-suited for city driving.
Equipment & Trim Levels
The 1.6 i ED trim level of the Palio Weekend typically included features such as power steering, central locking, and basic instrumentation. Interior upholstery was generally cloth, with a functional, if somewhat basic, dashboard layout. Air conditioning was often an optional extra, as were power windows and a radio/cassette player. The Weekend’s defining feature, of course, was its spacious cargo area, which could be expanded by folding down the rear seats. Safety features were relatively limited by modern standards, typically including only a driver’s airbag and seatbelts. The overall focus of the trim level was on providing a practical and affordable vehicle with essential features.
Chassis & Braking
The Palio Weekend 1.6 i ED utilized a front-wheel-drive layout with a relatively simple chassis design. The front suspension consisted of MacPherson struts, while the rear suspension employed a trailing arm setup. This configuration prioritized cost-effectiveness and ease of maintenance. Braking duties were handled by disc brakes at the front and drum brakes at the rear. The braking system was adequate for the car’s weight and performance, but lacked the stopping power of more advanced systems. The car’s relatively light weight (around 1080 kg or 2380 lbs) helped to offset the limitations of the braking system. Stabilizer bars were typically included to reduce body roll during cornering, but their effectiveness was limited.
Market Reception & Comparison
The Fiat Palio Weekend 1.6 i ED was generally well-received as a practical and affordable station wagon. Critics praised its spacious interior, reasonable fuel economy, and relatively low running costs. However, it was often criticized for its lack of refinement and its modest performance. Compared to other station wagons in its class, such as the Peugeot 206 SW or the Renault Clio Estate, the Palio Weekend offered a more basic driving experience but at a lower price point. The 1.6-liter engine provided a good balance between performance and fuel economy, making it a popular choice for budget-conscious buyers. The manual transmission was preferred by many drivers for its greater control and fuel efficiency compared to the optional automatic transmission.
Legacy
The Fiat Palio Weekend 1.6 i ED has proven to be a relatively reliable vehicle, with many examples still on the road today. The 1.6-liter engine is known for its durability, and routine maintenance is relatively straightforward and inexpensive. However, like any older vehicle, it is susceptible to age-related issues such as corrosion and wear and tear on suspension components. In the used car market, the Palio Weekend 1.6 i ED remains an affordable option for those seeking a practical and spacious station wagon. Its simplicity and reliability make it a good choice for first-time car owners or those looking for a dependable workhorse. While it may not offer the same level of refinement or performance as more modern vehicles, it continues to provide a valuable service to many drivers.
