The Land Rover Discovery Sport 2.0 SD4 AWD Automatic, produced from 2017 to 2018, represents a significant entry in the premium compact SUV segment. Positioned as a mid-to-high trim level within the first generation Discovery Sport (L550) range, it offered a blend of performance, luxury, and all-terrain capability. This variant utilized Land Rover’s Ingenium engine family, paired with a sophisticated nine-speed automatic transmission and a full-time all-wheel-drive system. It was designed to appeal to buyers seeking a versatile vehicle capable of both daily commuting and weekend adventures, while offering a more powerful alternative to the lower-spec engine options.
Technical Specifications
| Brand | Land Rover |
| Model | Discovery Sport |
| Type (Engine) | 2.0 SD4 (240 Hp) AWD Automatic |
| Start of production | 2017 |
| End of production | 2018 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Fuel consumption (combined) | 7.6-7.8 l/100 km (30.9 – 30.2 US mpg, 37.2 – 36.2 UK mpg, 13.2 – 12.8 km/l) |
| CO2 emissions | 181-186 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 7.6 sec |
| Acceleration 0 – 62 mph | 7.6 sec |
| Acceleration 0 – 60 mph | 7.2 sec |
| Maximum speed | 204 km/h (126.76 mph) |
| Weight-to-power ratio | 7.9 kg/Hp, 126.6 Hp/tonne |
| Weight-to-torque ratio | 3.8 kg/Nm, 263.7 Nm/tonne |
| Power | 240 Hp @ 4000 rpm |
| Power per litre | 120.1 Hp/l |
| Torque | 500 Nm @ 1500 rpm (368.78 lb.-ft. @ 1500 rpm) |
| Engine layout | Front, Transverse |
| Engine Model/Code | Ingenium / 204DTA |
| Engine displacement | 1999 cm3 (121.99 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 83 mm (3.27 in.) |
| Piston Stroke | 92.35 mm (3.64 in.) |
| Compression ratio | 15.34:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 6.5 l (6.87 US qt | 5.72 UK qt) |
| Coolant | 7.4 l (7.82 US qt | 6.51 UK qt) |
| Kerb Weight | 1896 kg (4179.96 lbs.) |
| Max. weight | 2550 kg (5621.79 lbs.) |
| Max load | 654 kg (1441.82 lbs.) |
| Trunk (boot) space – minimum | 981 l (34.64 cu. ft.) |
| Trunk (boot) space – maximum | 1698 l (59.96 cu. ft.) |
| Fuel tank capacity | 54 l (14.27 US gal | 11.88 UK gal) |
| Max. roof load | 75 kg (165.35 lbs.) |
| Permitted trailer load with brakes (12%) | 2500 kg (5511.56 lbs.) |
| Permitted trailer load without brakes | 750 kg (1653.47 lbs.) |
| Permitted towbar download | 100 kg (220.46 lbs.) |
| Length | 4599 mm (181.06 in.) |
| Width with mirrors folded | 2069 mm (81.46 in.) |
| Width including mirrors | 2173 mm (85.55 in.) |
| Height | 1724 mm (67.87 in.) |
| Wheelbase | 2741 mm (107.91 in.) |
| Front track | 1621 mm (63.82 in.) |
| Rear (Back) track | 1630 mm (64.17 in.) |
| Ride height (ground clearance) | 212 mm (8.35 in.) |
| Minimum turning circle | 11.86 m (38.91 ft.) |
| Approach angle | 23.4° |
| Departure angle | 31° |
| Ramp-over (brakeover) angle | 20° |
| Wading depth | 600 mm (23.62 in.) |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 9 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs, 349 mm |
| Rear brakes | Disc, 300 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 235/60 R18 107H |
| Wheel rims size | 8J x 18 ET45 |
Powertrain & Engine Architecture
The heart of the Discovery Sport 2.0 SD4 is Land Rover’s Ingenium engine family. Specifically, the 204DTA engine is a 2.0-liter inline-four cylinder diesel engine. This engine utilizes a cast aluminum block and cylinder head, designed for both lightweight construction and rigidity. The engine employs a sophisticated common-rail direct injection system, delivering fuel at pressures up to 2,000 bar for optimized combustion. A single turbocharger with variable geometry technology (VGT) provides enhanced responsiveness and power delivery across the rev range. The Ingenium engine also features a belt-in-the-rear configuration, which allows for a more compact engine design and improved NVH (Noise, Vibration, and Harshness) characteristics. Paired with the engine is a ZF 9HP48 nine-speed automatic transmission. This transmission is known for its smooth shifting and wide gear ratio spread, contributing to both fuel efficiency and performance. The transmission is electronically controlled and adapts to driving conditions and driver input.
Driving Characteristics
The 240 horsepower and 368 lb-ft of torque produced by the 2.0 SD4 engine provide brisk acceleration, with a 0-60 mph time of around 7.2 seconds. The nine-speed automatic transmission plays a crucial role in maximizing the engine’s output. The close gear ratios ensure the engine remains within its optimal power band during acceleration. While not as overtly sporty as some competitors, the Discovery Sport 2.0 SD4 offers a comfortable and capable driving experience. The all-wheel-drive system provides excellent traction in various conditions, making it suitable for both on-road and light off-road use. Compared to the lower-powered 180 hp diesel variant, the SD4 offers a noticeable improvement in performance, particularly during overtaking maneuvers and when carrying a full load. It doesn’t match the performance of the higher-spec petrol variants, but provides a good balance of power and fuel economy.
Equipment & Trim Levels
The 2.0 SD4 typically came well-equipped, sitting in the mid-to-upper range of the Discovery Sport lineup. Standard features included leather upholstery, automatic climate control, a touchscreen infotainment system with navigation, and a suite of safety features such as autonomous emergency braking and lane departure warning. Optional extras included a panoramic sunroof, premium audio system, adaptive cruise control, and various styling enhancements. Interior trim options varied, with choices in leather color and dashboard finishes. The overall interior design focused on a blend of modern aesthetics and practicality, with durable materials and ample storage space.
Chassis & Braking
The Discovery Sport utilizes a monocoque chassis construction, providing a good balance of rigidity and weight. The suspension system consists of McPherson struts at the front and a multi-link setup at the rear. This configuration delivers a comfortable ride quality while maintaining good handling characteristics. Braking duties are handled by ventilated discs at the front and solid discs at the rear. The vehicle is equipped with ABS (Anti-lock Braking System), Electronic Stability Control (ESC), and Traction Control. The steering system is an electric power-assisted rack and pinion setup, providing precise and responsive steering feel.
Market Reception & Comparison
The Land Rover Discovery Sport 2.0 SD4 was generally well-received by automotive critics. It was praised for its stylish design, spacious interior, and capable all-terrain performance. The Ingenium engine was lauded for its refinement and fuel efficiency. However, some critics noted that the infotainment system could be slow to respond at times. Compared to rivals such as the Audi Q3 and BMW X1, the Discovery Sport offered a more distinctive design and a greater emphasis on off-road capability. The 2.0 SD4 offered a compelling alternative to the lower-powered diesel variants, providing a noticeable performance boost without significantly compromising fuel economy.
Legacy
The Land Rover Discovery Sport 2.0 SD4 has proven to be a relatively reliable vehicle, although, like all modern vehicles, it is not without its potential issues. Common concerns include occasional issues with the infotainment system and, in some cases, problems with the diesel particulate filter (DPF). However, the Ingenium engine has generally proven to be durable and long-lasting. On the used car market, the 2.0 SD4 remains a popular choice, commanding a premium over the lower-spec variants. Its blend of performance, luxury, and capability continues to appeal to buyers seeking a versatile and stylish compact SUV.
