The Nissan Townstar Van is a compact panel van introduced in 2022, representing Nissan’s entry into the electric light commercial vehicle segment. Built in collaboration with Renault (and sharing significant components with the Renault Kangoo E-Tech Electric), the Townstar is primarily aimed at the European market, catering to businesses and tradespeople requiring a practical and efficient urban delivery vehicle. While not initially sold in the United States, it exemplifies the growing trend towards electric commercial vehicles globally. The 45 kWh variant, producing 122 horsepower, is a key model within the Townstar range, balancing range with payload capacity.
Nissan Townstar Van 45 kWh: An Overview
The Townstar Van replaces the older Nissan e-NV200, offering a more modern platform, increased range, and enhanced technology. It’s positioned as a versatile solution for last-mile deliveries, mobile workshops, and various commercial applications. The van’s design prioritizes practicality, with a focus on maximizing cargo space and minimizing running costs. The 45 kWh battery pack provides a competitive range for urban and regional operations, while the electric powertrain contributes to reduced emissions and noise pollution.
Engine & Performance
The Nissan Townstar Van 45 kWh is powered by a single electric motor, delivering 122 horsepower (Hp) and 245 Nm (180.7 lb.-ft.) of torque. This electric motor, designated model 5AQ 60, is mounted transversely at the front of the vehicle, driving the front wheels. The powertrain utilizes a single-speed automatic transmission, providing smooth and seamless acceleration. The van’s weight-to-power ratio is 13.2 kg/Hp, and 75.9 Hp/tonne, indicating a reasonable power output for its intended purpose. The electric powertrain provides instant torque, making it well-suited for stop-and-go city driving. Maximum speed is electronically limited to 132 km/h (82.02 mph). The system torque matches the motor torque at 245 Nm (180.7 lb.-ft.).
Design & Features
The Nissan Townstar Van is a five-door minivan designed with functionality in mind. Its exterior styling is modern and aerodynamic, contributing to improved energy efficiency. The van offers a spacious cargo area, with a minimum capacity of 3300 liters (116.54 cu. ft.) and a maximum capacity of 3900 liters (137.73 cu. ft.) when the rear seats are folded or removed. The vehicle’s dimensions are 4488 mm (176.69 in.) in length, 1859 mm (73.19 in.) in width, and 1822 mm (71.73 in.) in height. The wheelbase measures 2716 mm (106.93 in.).
Key features include a comfortable cabin with ergonomic seating, a user-friendly infotainment system, and a range of safety technologies. Standard safety equipment includes ABS (Anti-lock braking system). The Townstar also offers a variety of optional features, such as parking sensors, a rearview camera, and advanced driver-assistance systems (ADAS) to enhance safety and convenience. The van’s load capacity ranges from 387 to 622 kg (853.19 – 1371.28 lbs.), depending on the configuration. It can tow a braked trailer of up to 1500 kg (3306.93 lbs.) and an unbraked trailer of up to 750 kg (1653.47 lbs.).
Technical Specifications
| Brand | Nissan |
| Model | Townstar |
| Generation | Townstar Van |
| Type (Engine) | 45 kWh (122 Hp) EV |
| Start of production | August, 2022 |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | Minivan |
| Seats | 2 |
| Doors | 5 |
| Fuel Type | Electricity |
| Maximum speed | 132 km/h (82.02 mph) |
| Weight-to-power ratio | 13.2 kg/Hp |
| Weight-to-torque ratio | 6.6 kg/Nm |
| Gross battery capacity | 45 kWh |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Under the trunk |
| All-electric range (WLTP) | 301 km (187.03 mi) |
| Average Energy consumption (WLTP) | 17.4-35.1 kWh/100 km (28 – 56.49 kWh/100 mi) |
| Electric motor power | 122 Hp |
| Electric motor Torque | 245 Nm (180.7 lb.-ft.) |
| Electric motor model/code | 5AQ 60 |
| Electric motor location | Front, Transverse |
| System power | 122 Hp |
| System torque | 245 Nm (180.7 lb.-ft.) |
| Kerb Weight | 1608-1843 kg (3545.03 – 4063.12 lbs.) |
| Max. weight | 2230 kg (4916.31 lbs.) |
| Max load | 387-622 kg (853.19 – 1371.28 lbs.) |
| Trunk (boot) space – minimum | 3300 l (116.54 cu. ft.) |
| Trunk (boot) space – maximum | 3900 l (137.73 cu. ft.) |
| Max. roof load | 100 kg (220.46 lbs.) |
| Permitted trailer load with brakes (12%) | 1500 kg (3306.93 lbs.) |
| Permitted trailer load without brakes | 750 kg (1653.47 lbs.) |
| Permitted towbar download | 75 kg (165.35 lbs.) |
| Length | 4488 mm (176.69 in.) |
| Width | 1859 mm (73.19 in.) |
| Width including mirrors | 2159 mm (85 in.) |
| Height | 1822 mm (71.73 in.) |
| Wheelbase | 2716 mm (106.93 in.) |
| Front track | 1570 mm (61.81 in.) |
| Rear (Back) track | 1584 mm (62.36 in.) |
| Front overhang | 962 mm (37.87 in.) |
| Rear overhang | 810 mm (31.89 in.) |
| Minimum turning circle (turning diameter) | 11.75 m (38.55 ft.) |
| Drivetrain Architecture | One electric motor drives the front wheels. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 205/60 R16 96H XL |
| Wheel rims size | 6.0J x 16 |
The Nissan Townstar Van 45 kWh represents a significant step forward in Nissan’s electric commercial vehicle offerings. Its combination of practicality, efficiency, and modern technology makes it a compelling option for businesses seeking a sustainable and cost-effective solution for their transportation needs. While currently focused on the European market, the Townstar demonstrates Nissan’s commitment to electrification and its ability to adapt to the evolving demands of the commercial vehicle sector.
