The Renault Grand Scenic IV (Phase I) 1.3 TCe (160 Hp) EDC FAP 7 Seat is a compact minivan produced by the French manufacturer Renault from September 2018 to October 2020. Representing the fourth generation of the Scenic line, the Grand Scenic IV aimed to blend practicality, technology, and a comfortable driving experience within the European family vehicle market. While not officially sold in the United States, the Scenic has been a popular choice in Europe for families seeking a versatile and spacious vehicle. This particular variant, equipped with a 1.3-liter turbocharged gasoline engine and a seven-speed dual-clutch transmission (EDC), offered a balance of performance and fuel efficiency.
Renault Grand Scenic IV: Overview
The Grand Scenic IV is part of Renault’s strategy to offer a comprehensive range of family vehicles. It distinguishes itself from the standard Scenic through its seven-seat configuration, providing increased passenger capacity. The Phase I designation refers to the initial production run of the fourth generation, characterized by specific styling and equipment levels. The 1.3 TCe engine was a key component of Renault’s powertrain lineup during this period, offering a modern and efficient alternative to larger displacement engines.
Engine & Performance
The Renault Grand Scenic IV 1.3 TCe is powered by a 1.3-liter inline-four cylinder turbocharged gasoline engine, designated H5H. This engine produces 160 horsepower at 5500 rpm and 270 Nm (199.14 lb.-ft.) of torque at 1800 rpm. The engine utilizes direct fuel injection and an intercooler to enhance performance and efficiency. Power is delivered to the front wheels via a seven-speed Efficient Dual Clutch (EDC) automatic transmission. This transmission provides smooth and rapid gear changes, contributing to a responsive driving experience. Performance figures include a 0-100 km/h (0-62 mph) acceleration time of 9.9 seconds and a top speed of 207 km/h (128.62 mph). The vehicle’s weight-to-power ratio is 10.2 kg/Hp, and its weight-to-torque ratio is 6 kg/Nm.
Design & Features
The Grand Scenic IV features a distinctive exterior design with a sculpted body and a prominent front grille. Its minivan body style prioritizes interior space and practicality. The vehicle offers seating for seven passengers across three rows, making it suitable for larger families. Key features include a modern dashboard layout with a large touchscreen infotainment system, advanced driver-assistance systems (ADAS) such as automatic emergency braking and lane departure warning, and a spacious and versatile interior. The trunk space, with all seats in place, is 189 liters (6.67 cu. ft.), expanding significantly when the rear seats are folded down. The vehicle’s dimensions are 4634 mm (182.44 in.) in length, 1866 mm (73.46 in.) in width, and 1660-1655 mm (65.35 – 65.16 in.) in height. The Grand Scenic IV is equipped with a particulate filter to meet Euro 6 emission standards.
Technical Specifications
| Brand | Renault |
| Model | Scenic |
| Generation | Grand Scenic IV (Phase I) |
| Type | 1.3 TCe (160 Hp) EDC FAP 7 Seat |
| Start of production | September, 2018 |
| End of production | October, 2020 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan |
| Seats | 7 |
| Doors | 5 |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 9.9 sec |
| Acceleration 0 – 62 mph | 9.9 sec |
| Acceleration 0 – 60 mph | 9.4 sec |
| Maximum speed | 207 km/h (128.62 mph) |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 10.2 kg/Hp |
| Weight-to-torque ratio | 6 kg/Nm |
| Power | 160 Hp @ 5500 rpm |
| Torque | 270 Nm @ 1800 rpm (199.14 lb.-ft. @ 1800 rpm) |
| Engine layout | Front, Transverse |
| Engine Model/Code | H5H |
| Engine displacement | 1332 cm3 (81.28 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 5.5 l (5.81 US qt | 4.84 UK qt) |
| Coolant | 6.5 l (6.87 US qt | 5.72 UK qt) |
| Kerb Weight | 1632 kg (3597.94 lbs) |
| Max. weight | 2245 kg (4949.38 lbs) |
| Max load | 613 kg (1351.43 lbs) |
| Trunk (boot) space – minimum | 189 l (6.67 cu. ft.) |
| Fuel tank capacity | 53 l (14 US gal | 11.66 UK gal) |
| Max. roof load | 80 kg (176.37 lbs) |
| Permitted trailer load with brakes (12%) | 1800 kg (3968.32 lbs) |
| Permitted trailer load without brakes | 750 kg (1653.47 lbs) |
| Length | 4634 mm (182.44 in) |
| Width | 1866 mm (73.46 in) |
| Width including mirrors | 2128 mm (83.78 in) |
| Height | 1660-1655 mm (65.35 – 65.16 in) |
| Wheelbase | 2804 mm (110.39 in) |
| Front track | 1602 mm (63.07 in) |
| Rear (Back) track | 1596 mm (62.83 in) |
| Drivetrain Architecture | Front wheel drive |
| Number of gears and type of gearbox | 7 gears, automatic transmission EDC |
| Front suspension | Independent type McPherson |
| Rear suspension | Semi-independent, coil spring |
| Front brakes | Ventilated discs, 320 mm |
| Rear brakes | Disc, 290 mm |
| Tires size | 195/55 R20 |
| Wheel rims size | 20 |
The Renault Grand Scenic IV (Phase I) 1.3 TCe (160 Hp) EDC FAP 7 Seat represented a significant offering in the European minivan segment, combining practicality, efficiency, and a comfortable driving experience. Its seven-seat configuration and advanced features made it a popular choice for families, while its modern powertrain and design ensured it remained competitive in a rapidly evolving automotive market.
