The Renault Kangoo Be Bop 1.6 16V, produced from 2009 to 2010, represents a unique and somewhat quirky iteration of Renault’s popular Kangoo van. Positioned as a lifestyle-oriented vehicle, the Be Bop distinguished itself from the standard Kangoo panel van and passenger versions with its distinctive three-door hatchback configuration and more car-like styling. It was primarily marketed in Europe as a compact, versatile vehicle aimed at individuals and small families seeking a blend of practicality and individuality. This particular variant, equipped with the 1.6-liter 16-valve engine producing 106 horsepower, occupied a mid-range position within the Be Bop lineup, offering a balance between performance and fuel economy.
Technical Specifications
| Brand | Renault |
| Model | Kangoo |
| Generation | Kangoo Be Bop |
| Type (Engine) | 1.6 16V (106 Hp) |
| Start of production | 2009 |
| End of production | 2010 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 4 |
| Doors | 3 |
| Fuel consumption (urban) | 10.6 l/100 km (22.2 US mpg, 26.6 UK mpg, 9.4 km/l) |
| Fuel consumption (extra urban) | 6.3 l/100 km (37.3 US mpg, 44.8 UK mpg, 15.9 km/l) |
| Fuel consumption (combined) | 7.9 l/100 km (29.8 US mpg, 35.8 UK mpg, 12.7 km/l) |
| CO2 emissions | 191 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 12.1 sec |
| Acceleration 0 – 62 mph | 12.1 sec |
| Acceleration 0 – 60 mph | 11.5 sec |
| Maximum speed | 170 km/h (105.63 mph) |
| Emission standard | Euro 4 |
| Weight-to-power ratio | 13.5 kg/Hp, 73.9 Hp/tonne |
| Weight-to-torque ratio | 9.7 kg/Nm, 103.1 Nm/tonne |
| Power | 106 Hp @ 5750 rpm |
| Power per litre | 66.3 Hp/l |
| Torque | 148 Nm @ 3750 rpm (109.16 lb.-ft. @ 3750 rpm) |
| Engine layout | Front, Transverse |
| Engine Model/Code | K4M |
| Engine displacement | 1598 cm3 (97.52 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 79.5 mm (3.13 in.) |
| Piston Stroke | 80.5 mm (3.17 in.) |
| Compression ratio | 9.7:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Engine oil capacity | 4.8 l (5.07 US qt | 4.22 UK qt) |
| Coolant | 5 l (5.28 US qt | 4.4 UK qt) |
| Kerb Weight | 1435 kg (3163.63 lbs.) |
| Max. weight | 1837 kg (4049.89 lbs.) |
| Max load | 402 kg (886.26 lbs.) |
| Trunk (boot) space – minimum | 214 l (7.56 cu. ft.) |
| Trunk (boot) space – maximum | 1462 l (51.63 cu. ft.) |
| Fuel tank capacity | 60 l (15.85 US gal | 13.2 UK gal) |
| Permitted trailer load with brakes (12%) | 1050 kg (2314.85 lbs.) |
| Permitted trailer load without brakes | 697 kg (1536.62 lbs.) |
| Permitted towbar download | 75 kg (165.35 lbs.) |
| Length | 3871 mm (152.4 in.) |
| Width including mirrors | 2133 mm (83.98 in.) |
| Height | 1847 mm (72.72 in.) |
| Wheelbase | 2313 mm (91.06 in.) |
| Front track | 1519 mm (59.8 in.) |
| Rear (Back) track | 1533 mm (60.35 in.) |
| Front overhang | 826 mm (32.52 in.) |
| Rear overhang | 732 mm (28.82 in.) |
| Ride height (ground clearance) | 215 mm (8.46 in.) |
| Minimum turning circle (turning diameter) | 9.6 m (31.5 ft.) |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Independent coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Steering type | Steering rack and pinion |
| Tires size | 205/60 R16 |
| Wheel rims size | 16 |
Powertrain & Engine Architecture
The heart of the Kangoo Be Bop 1.6 16V is the K4M engine, a naturally aspirated, inline-four cylinder gasoline engine. This engine was a mainstay in Renault’s lineup for many years, known for its relative simplicity and durability. The ‘16V’ designation indicates the engine features four valves per cylinder, enhancing breathing and contributing to its power output. Fuel delivery is managed by a multi-port fuel injection system, providing precise fuel metering for optimal combustion. The engine produces 106 horsepower at 5750 rpm and 148 Nm (109.16 lb-ft) of torque at 3750 rpm. The engine’s 9.7:1 compression ratio is a typical value for a naturally aspirated gasoline engine of this era. The five-speed manual transmission was the standard offering, providing adequate gear ratios for everyday driving. While an automatic transmission was available in some Kangoo models, it was less common with the 1.6 16V engine.
Driving Characteristics
The 1.6 16V engine, paired with the five-speed manual transmission, provided adequate, though not exhilarating, performance in the Kangoo Be Bop. Acceleration from 0 to 60 mph took around 11.5 seconds, and the top speed was approximately 105.63 mph. The engine felt reasonably responsive in the mid-range, making it suitable for urban and highway driving. However, it lacked the punch of more powerful engines found in other Kangoo variants. The gear ratios were well-spaced, allowing for comfortable cruising at highway speeds. Compared to the diesel versions, the 1.6 16V offered a smoother and quieter driving experience, but at the expense of fuel economy and low-end torque. The relatively lightweight nature of the Be Bop helped to mitigate the engine’s modest power output.
Equipment & Trim Levels
The Kangoo Be Bop 1.6 16V typically came with a reasonable level of standard equipment. This included power steering, central locking, electric front windows, and an adjustable steering column. Interior upholstery was typically cloth, with a functional and durable design. Optional extras included air conditioning, alloy wheels, and a CD player. The Be Bop’s interior was designed with practicality in mind, featuring numerous storage compartments and a flexible seating arrangement. The distinctive exterior styling, with its rounded shape and large windows, contributed to its unique appeal.
Chassis & Braking
The Kangoo Be Bop utilized a front-wheel-drive layout with an independent coil spring suspension at the front and a twist beam suspension at the rear. The front brakes were ventilated discs, providing good stopping power, while the rear brakes were discs. The steering was a rack and pinion system, offering precise and responsive handling. The suspension setup provided a comfortable ride, absorbing bumps and imperfections in the road surface effectively. The 205/60 R16 tires provided adequate grip in most driving conditions.
Market Reception & Comparison
The Renault Kangoo Be Bop 1.6 16V received mixed reviews from automotive critics. While its quirky styling and practicality were appreciated, some criticized its modest performance and relatively high price compared to other small hatchbacks. Fuel economy was considered average for a gasoline engine of this size. Compared to the diesel-powered Kangoo models, the 1.6 16V offered a more refined driving experience but suffered from lower fuel efficiency and reduced torque. The Be Bop’s unique three-door configuration limited its practicality for families with young children.
Legacy
The Renault Kangoo Be Bop 1.6 16V, while a relatively short-lived model, has gained a cult following among enthusiasts who appreciate its distinctive styling and practicality. The K4M engine is known for its reliability and relatively low maintenance costs. Used examples are still available today, often at affordable prices. However, potential buyers should be aware of potential issues such as corrosion and wear and tear on suspension components. Overall, the Kangoo Be Bop 1.6 16V remains a charming and versatile vehicle that offers a unique alternative to more conventional small hatchbacks.
