The Toyota Avensis III (facelift, introduced in 2012) 2.2 D-CAT 150 hp variant represented a significant offering in the mid-size sedan segment, particularly within the European market. Produced from 2012 to 2015, this version of the Avensis aimed to balance fuel efficiency with respectable performance, appealing to drivers seeking a comfortable and reliable family vehicle. It sat within the broader Avensis III range (platform T27), which was known for its practicality and build quality, positioned as a competitor to the Ford Mondeo, Vauxhall/Opel Insignia, and Volkswagen Passat.
Technical Specifications
| Brand | Toyota |
| Model | Avensis |
| Generation | Avensis III (facelift 2012) |
| Type (Engine) | 2.2 D-CAT (150 Hp) |
| Start of production | 2012 |
| End of production | 2015 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Fuel consumption (urban) | 7.3 l/100 km (32.2 US mpg, 38.7 UK mpg, 13.7 km/l) |
| Fuel consumption (extra urban) | 4.8 l/100 km (49 US mpg, 58.9 UK mpg, 20.8 km/l) |
| Fuel consumption (combined) | 5.8 l/100 km (40.6 US mpg, 48.7 UK mpg, 17.2 km/l) |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 8.5 sec |
| Acceleration 0 – 62 mph | 8.5 sec |
| Acceleration 0 – 60 mph | 8.1 sec |
| Maximum speed | 220 km/h (136.7 mph) |
| Emission standard | Euro 5 B |
| Weight-to-power ratio | 10.2 kg/Hp, 98 Hp/tonne |
| Weight-to-torque ratio | 4.5 kg/Nm, 222.2 Nm/tonne |
| Power | 150 Hp @ 3600 rpm |
| Power per litre | 67.2 Hp/l |
| Torque | 340 Nm @ 2800 rpm (250.77 lb.-ft. @ 2800 rpm) |
| Engine layout | Front, Transverse |
| Engine Model/Code | 2AD-FHV |
| Engine displacement | 2231 cm3 (136.14 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 86 mm (3.39 in.) |
| Piston Stroke | 96 mm (3.78 in.) |
| Compression ratio | 15.7:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 5.9 l (6.23 US qt | 5.19 UK qt) |
| Coolant | 7.4 l (7.82 US qt | 6.51 UK qt) |
| Kerb Weight | 1530 kg (3373.07 lbs.) |
| Max. weight | 2140 kg (4717.89 lbs.) |
| Max load | 610 kg (1344.82 lbs.) |
| Trunk (boot) space – minimum | 509 l (17.98 cu. ft.) |
| Fuel tank capacity | 60 l (15.85 US gal | 13.2 UK gal) |
| Length | 4710 mm (185.43 in.) |
| Width | 1810 mm (71.26 in.) |
| Height | 1480 mm (58.27 in.) |
| Wheelbase | 2700 mm (106.3 in.) |
| Front track | 1550 mm (61.02 in.) |
| Rear (Back) track | 1540 mm (60.63 in.) |
| Minimum turning circle | 10.8 m (35.43 ft.) |
| Drivetrain Architecture | Front wheel drive |
| Number of gears | 6 |
| Gearbox type | Manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Double wishbone |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 215/55 R17 |
| Wheel rims size | 17 |
INTRODUCTION
The 2012 facelift of the Toyota Avensis III brought with it revised styling, updated technology, and refinements to the engine lineup. The 2.2 D-CAT engine, designated with the 2AD-FHV engine code, was a key component of this update. This engine offered a balance between performance and fuel economy, making it a popular choice for drivers covering long distances. The 150 hp output, coupled with a six-speed manual transmission, positioned this variant as a solid mid-range option within the Avensis lineup, appealing to both private buyers and fleet operators.
Powertrain & Engine Architecture
The 2AD-FHV is a 2.2-liter inline-four cylinder diesel engine. It utilizes a common rail direct injection system, delivering fuel at extremely high pressure for optimized combustion. The engine features a turbocharger with an intercooler, enhancing power output and efficiency. The D-CAT (Diesel Clean Advanced Technology) system incorporates a Diesel Particulate Filter (DPF) to reduce particulate matter emissions, meeting stringent Euro 5 emission standards. The valvetrain is a Double Overhead Camshaft (DOHC) configuration with four valves per cylinder, contributing to improved breathing and overall engine performance. The six-speed manual transmission was chosen for its efficiency and driver engagement, offering precise gear changes and contributing to the vehicle’s overall responsiveness.
Driving Characteristics
The Avensis 2.2 D-CAT 150 hp offered a comfortable and refined driving experience. While not a sports sedan, the engine provided ample torque – 340 Nm (250.77 lb.-ft.) – from 2800 rpm, making it capable of effortless cruising and confident overtaking. The six-speed manual transmission allowed drivers to keep the engine within its optimal power band. Acceleration from 0-60 mph took approximately 8.1 seconds, which was competitive for its class. Compared to the lower-powered 1.6-liter petrol variants, the 2.2 D-CAT offered significantly more pulling power, especially when fully loaded. However, it didn’t possess the outright performance of higher-spec Avensis models equipped with more powerful engines. The gear ratios were well-chosen for both highway driving and urban commutes, providing a balance between fuel efficiency and responsiveness.
Equipment & Trim Levels
The 2.2 D-CAT 150 hp variant was typically offered in mid-range trim levels, such as ‘Comfort’ or ‘Style’ depending on the specific market. Standard equipment generally included air conditioning, power windows, central locking, a CD/radio system with auxiliary input, and alloy wheels. Higher trim levels added features like automatic climate control, cruise control, rear parking sensors, and a touchscreen infotainment system. Interior upholstery was typically cloth, with options for leather upgrades. Safety features included ABS, Electronic Brakeforce Distribution (EBD), and multiple airbags. Optional extras often included a sunroof, navigation system, and upgraded audio systems.
Chassis & Braking
The Avensis III utilized a McPherson strut front suspension setup with a coil spring and anti-roll bar, providing a comfortable ride and predictable handling. The rear suspension employed a double wishbone configuration, further enhancing ride quality and stability. The braking system consisted of ventilated discs on the front wheels and solid discs on the rear, providing adequate stopping power for the vehicle’s weight. ABS (Anti-lock Braking System) was standard, enhancing safety during emergency braking situations. The steering was a rack and pinion system, offering precise and responsive control.
Market Reception & Comparison
The Toyota Avensis 2.2 D-CAT 150 hp was generally well-received by automotive critics. It was praised for its comfortable ride, spacious interior, and fuel efficiency. The diesel engine was noted for its refinement and strong torque delivery. However, some critics found the styling to be somewhat conservative compared to rivals. Compared to the petrol-powered Avensis models, the 2.2 D-CAT offered significantly better fuel economy, making it a more cost-effective option for high-mileage drivers. Against competitors like the Ford Mondeo and Volkswagen Passat, the Avensis was often seen as a more reliable and durable option, although it may have lacked the same level of driving excitement.
Legacy
The 2AD-FHV engine, while generally reliable, is known to require regular maintenance, particularly regarding the Diesel Particulate Filter (DPF). Proper servicing and the use of high-quality diesel fuel are crucial to prevent DPF blockages. On the used car market, the Avensis 2.2 D-CAT 150 hp remains a popular choice due to its reputation for reliability and affordability. Models with a well-documented service history and lower mileage tend to command higher prices. The Avensis continues to be regarded as a practical and dependable family sedan, offering a good balance of comfort, efficiency, and durability.
