The Toyota Avensis (T22) 2.0 16V Automatic, produced between 2000 and 2003, represented a mid-range offering within the second generation Avensis lineup. Positioned as a comfortable and practical family sedan, it aimed to provide a balance between performance and fuel efficiency. The T22 generation Avensis was Toyota’s attempt to create a truly global mid-size car, designed to appeal to both European and Asian markets, and compete directly with established rivals like the Ford Mondeo and Volkswagen Passat. This particular variant, with its 2.0-liter engine and automatic transmission, was a popular choice for buyers prioritizing ease of driving over outright sportiness.
Technical Specifications
| Brand | Toyota |
| Model | Avensis |
| Generation | Avensis (T22) |
| Type (Engine) | 2.0 16V (150 Hp) Automatic |
| Start of production | 2000 |
| End of production | 2003 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Fuel consumption (urban) | 11.9 l/100 km (19.8 US mpg, 23.7 UK mpg, 8.4 km/l) |
| Fuel consumption (extra urban) | 6.9 l/100 km (34.1 US mpg, 40.9 UK mpg, 14.5 km/l) |
| Fuel consumption (combined) | 8.6 l/100 km (27.4 US mpg, 32.8 UK mpg, 11.6 km/l) |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 9.9 sec |
| Acceleration 0 – 62 mph | 9.9 sec |
| Acceleration 0 – 60 mph | 9.4 sec |
| Maximum speed | 205 km/h (127.38 mph) |
| Weight-to-power ratio | 8.3 kg/Hp, 120.5 Hp/tonne |
| Weight-to-torque ratio | 6.5 kg/Nm, 154.2 Nm/tonne |
| Power | 150 Hp @ 6000 rpm |
| Power per litre | 75.1 Hp/l |
| Torque | 192 Nm @ 4000 rpm (141.61 lb.-ft. @ 4000 rpm) |
| Engine layout | Front, Transverse |
| Engine Model/Code | 1AZ-FSE |
| Engine displacement | 1998 cm3 (121.93 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 86 mm (3.39 in.) |
| Piston Stroke | 86 mm (3.39 in.) |
| Compression ratio | 9.8:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 4.2 l (4.44 US qt | 3.7 UK qt) |
| Coolant | 8.3 l (8.77 US qt | 7.3 UK qt) |
| Kerb Weight | 1245 kg (2744.76 lbs.) |
| Max. weight | 1800 kg (3968.32 lbs.) |
| Max load | 555 kg (1223.57 lbs.) |
| Trunk (boot) space – minimum | 500 l (17.66 cu. ft.) |
| Fuel tank capacity | 60 l (15.85 US gal | 13.2 UK gal) |
| Length | 4490 mm (176.77 in.) |
| Width | 1710 mm (67.32 in.) |
| Height | 1425 mm (56.1 in.) |
| Wheelbase | 2630 mm (103.54 in.) |
| Front track | 1480 mm (58.27 in.) |
| Rear (Back) track | 1450 mm (57.09 in.) |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 4 gears, automatic transmission |
| Front suspension | Spring Strut |
| Rear suspension | Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 185/65 R14 |
| Wheel rims size | 14 |
Powertrain & Engine Architecture
The heart of the Avensis 2.0 Automatic is the 1AZ-FSE engine, a 1.998-liter (2.0L) inline-four cylinder gasoline engine. This engine utilizes a multi-port fuel injection system and a double overhead camshaft (DOHC) valvetrain, contributing to its relatively smooth power delivery. The 1AZ-FSE was known for its reliability and decent performance, though it wasn’t considered a particularly groundbreaking engine in terms of technology. The automatic transmission paired with this engine is a conventional four-speed unit. While not offering the efficiency of modern transmissions with more gears, it provided smooth and predictable shifts, making it well-suited for everyday driving. The transmission was designed to prioritize comfort and ease of use over sporty responsiveness.
Driving Characteristics
The 150 horsepower and 192 Nm (141.61 lb-ft) of torque produced by the 2.0-liter engine, when coupled with the four-speed automatic transmission, resulted in a comfortable but not particularly exhilarating driving experience. Acceleration from 0-60 mph took around 9.4 seconds, and top speed was approximately 127.38 mph. Compared to the manual transmission version of the same engine, the automatic suffered a slight performance penalty due to the inherent losses in the torque converter. However, the automatic offered a more relaxed driving experience, particularly in urban traffic. The gear ratios were tuned for fuel efficiency and smooth cruising, rather than aggressive acceleration. Compared to higher-output variants like the 2.4L engine, this 2.0L automatic was noticeably less powerful, but it offered better fuel economy and a lower purchase price.
Equipment & Trim Levels
The 2.0 16V Automatic trim typically included features such as air conditioning, power windows, central locking, and an integrated audio system. Interior upholstery was generally cloth, with options for upgraded materials available. Depending on the specific market and optional packages selected, features like alloy wheels, a sunroof, and upgraded sound systems could also be included. The Avensis aimed for a comfortable and well-equipped interior, though it didn’t necessarily compete with premium brands in terms of luxury.
Chassis & Braking
The Avensis T22 utilized a front-wheel-drive layout with a MacPherson strut front suspension and a coil spring rear suspension. This setup provided a comfortable ride quality, though it wasn’t particularly sporty in handling. The braking system consisted of ventilated discs on the front wheels and solid discs on the rear. Anti-lock Braking System (ABS) was standard, enhancing safety. The suspension was tuned for comfort and stability, prioritizing a smooth ride over sharp handling.
Market Reception & Comparison
The Avensis 2.0 16V Automatic was generally well-received by critics as a practical and reliable family car. It offered a good balance of comfort, fuel economy, and equipment. However, it wasn’t considered a particularly exciting car to drive, and its styling was often described as conservative. Compared to other trims in the Avensis lineup, the 2.0L automatic offered a more affordable entry point, but it lacked the performance of the higher-output engines. Fuel economy was competitive for its class, averaging around 27.4 US mpg in combined driving.
Legacy
The 1AZ-FSE engine, when properly maintained, proved to be a durable and reliable unit. The four-speed automatic transmission, while not the most advanced, also demonstrated good longevity. Today, used Avensis T22 models with this powertrain are often sought after for their affordability and reputation for reliability. However, potential buyers should be aware of the age-related issues common to older vehicles, such as corrosion and wear and tear on suspension components. The Avensis 2.0 16V Automatic remains a sensible choice for those seeking a dependable and economical used family sedan.
