The Toyota Calya (facelift 2019) 1.2i with an automatic transmission represents an entry-level variant within the Calya MPV (Multi-Purpose Vehicle) range. Introduced in September 2019 as part of a mid-cycle refresh, this model aimed to provide affordable, family-oriented transportation, particularly in Southeast Asian markets like Indonesia and the Philippines. The Calya, and its twin the Daihatsu Sigra, were designed to fill a gap in the market for a seven-seater vehicle at a competitive price point. This 1.2i Automatic trim served as the base model, offering essential features and prioritizing fuel efficiency over outright performance. It’s built on Toyota’s IMV platform, known for its robustness and cost-effectiveness.
Technical Specifications
| Brand | Toyota |
| Model | Calya |
| Generation | Calya (facelift 2019) |
| Type (Engine) | 1.2i (88 Hp) Automatic |
| Start of production | September, 2019 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | MPV |
| Seats | 7 |
| Doors | 5 |
| Fuel Type | Petrol (Gasoline) |
| Power | 88 Hp @ 6000 rpm |
| Power per litre | 73.5 Hp/l |
| Torque | 108 Nm @ 4200 rpm / 79.66 lb.-ft. @ 4200 rpm |
| Engine layout | Front, Transverse |
| Engine Model/Code | 3NR-VE |
| Engine displacement | 1197 cm3 / 73.05 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 72.5 mm / 2.85 in. |
| Piston Stroke | 72.5 mm / 2.85 in. |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC, D-VVT-i |
| Engine oil capacity | 3.5 l / 3.7 US qt | 3.08 UK qt |
| Coolant | 4 l / 4.23 US qt | 3.52 UK qt |
| Fuel tank capacity | 36 l / 9.51 US gal | 7.92 UK gal |
| Length | 4070 mm / 160.24 in. |
| Width | 1655 mm / 65.16 in. |
| Height | 1600 mm / 62.99 in. |
| Wheelbase | 2525 mm / 99.41 in. |
| Front overhang | 630 mm / 24.8 in. |
| Rear overhang | 915 mm / 36.02 in. |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 4 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Torsion |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 175/65 R14 |
| Wheel rims size | 14 |
Powertrain & Engine Architecture
The heart of the Calya 1.2i Automatic is the 3NR-VE engine, a 1.2-liter inline-four cylinder gasoline engine. This engine utilizes a multi-point fuel injection system and is naturally aspirated. The 3NR-VE is part of Toyota’s NR engine family, known for its balance of fuel efficiency and reliability. It features a Double Overhead Camshaft (DOHC) valvetrain with Dual Variable Valve Timing-intelligent (D-VVT-i) technology. D-VVT-i optimizes valve timing based on driving conditions, improving both power delivery and fuel economy. The engine produces 88 horsepower at 6000 rpm and 108 Nm (79.66 lb-ft) of torque at 4200 rpm. The engine is paired with a four-speed automatic transmission. This transmission was chosen for its simplicity and cost-effectiveness, rather than for sporting performance. It’s a conventional hydraulic automatic, lacking the more advanced features found in newer transmissions.
Driving Characteristics
The 1.2i Automatic Calya prioritizes practicality and ease of driving over performance. Acceleration is modest, and the four-speed automatic transmission has relatively wide gear ratios. This means the engine often operates at higher rpm during highway cruising, which can result in noticeable engine noise. The transmission is tuned for smooth shifts, but lacks the responsiveness of more modern automatic gearboxes. The relatively low horsepower and torque figures mean that fully loading the vehicle with passengers and luggage will significantly impact performance, especially on inclines. Compared to potential higher-spec Calya variants (if offered in some markets) with larger engines, the 1.2i Automatic provides a more economical but less spirited driving experience. The focus is on comfortable and predictable operation for everyday commuting and family transport.
Equipment & Trim Levels
As the entry-level trim, the Calya 1.2i Automatic typically comes with a basic set of features. Standard equipment generally includes air conditioning, power windows, central locking, and a basic audio system. Safety features usually consist of ABS (Anti-lock Braking System) and dual front airbags. Interior upholstery is typically cloth, and the dashboard features a functional but simple design. Optional extras, depending on the market, could include alloy wheels, a touchscreen infotainment system, and rear parking sensors. The interior is designed for durability and ease of cleaning, reflecting its family-oriented target audience.
Chassis & Braking
The Calya utilizes a front-engine, front-wheel-drive layout. The front suspension consists of an independent McPherson strut setup with coil springs and an anti-roll bar, providing a reasonable level of ride comfort. The rear suspension employs a torsion beam axle, a cost-effective and space-saving design. The braking system features ventilated discs on the front wheels and drum brakes on the rear. This configuration is typical for vehicles in this price segment. The steering is a rack and pinion system with electric power steering, offering light and easy maneuverability.
Market Reception & Comparison
The Toyota Calya 1.2i Automatic was generally well-received in its target markets as an affordable and practical seven-seater. Critics praised its spacious interior and fuel efficiency. However, the engine’s limited power and the four-speed automatic transmission were often cited as drawbacks. Compared to other MPVs in the same class, such as the Mitsubishi Xpander or Honda Mobilio (depending on the market), the Calya offered a more budget-friendly option, but with compromises in performance and refinement. Fuel economy is a strong point, making it an attractive option for cost-conscious buyers. Reliability is also a key strength, benefiting from Toyota’s reputation for building durable vehicles.
Legacy
The Toyota Calya 1.2i Automatic has established itself as a popular choice in the used car market, particularly for families seeking an affordable and reliable MPV. The 3NR-VE engine is known for its durability, and the simple automatic transmission is relatively easy to maintain. While not a performance vehicle, the Calya 1.2i Automatic provides a practical and economical transportation solution. Its continued presence on the used car market demonstrates its enduring appeal and Toyota’s success in meeting the demands of budget-conscious consumers in Southeast Asia.
