The Toyota Corolla Cross 1.8 Sport, equipped with a 140 horsepower engine and a CVT-i transmission, was a key variant in the Corolla Cross lineup produced from July 2020 to October 2023. Introduced as part of the first generation of the Corolla Cross (Z60 series), this model aimed to bridge the gap between affordability and a more engaging driving experience within the compact SUV segment. Positioned as a mid-range trim, the 1.8 Sport offered a balance of features and performance, appealing to buyers seeking a practical and fuel-efficient vehicle with a touch of sporty styling. It was primarily marketed in regions where compact SUVs were gaining significant popularity, including Asia, South America, and parts of Europe, though it wasn’t initially offered in the North American market.
Technical Specifications
| Brand | Toyota |
| Model | Corolla Cross |
| Generation | Corolla Cross |
| Type (Engine) | 1.8 Sport (140 Hp) CVT-i |
| Start of production | July, 2020 |
| End of production | October, 2023 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Fuel Type | Petrol (Gasoline) |
| Power | 140 Hp @ 6000 rpm |
| Power per litre | 77.9 Hp/l |
| Torque | 177 Nm @ 4000 rpm |
| Torque (lb.-ft.) | 130.55 lb.-ft. @ 4000 rpm |
| Engine Model/Code | 2ZR-FAE |
| Engine displacement | 1798 cm3 |
| Engine displacement (cu. in.) | 109.72 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 80.49 mm |
| Cylinder Bore (in.) | 3.17 in. |
| Piston Stroke | 88.29 mm |
| Piston Stroke (in.) | 3.48 in. |
| Compression ratio | 10:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 4.2 l |
| Engine oil capacity (US qt) | 4.44 US qt |
| Engine oil capacity (UK qt) | 3.7 UK qt |
| Coolant | 5.8 l |
| Coolant (US qt) | 6.13 US qt |
| Coolant (UK qt) | 5.1 UK qt |
| Fuel tank capacity | 47 l |
| Fuel tank capacity (US gal) | 12.42 US gal |
| Fuel tank capacity (UK gal) | 10.34 UK gal |
| Length | 4460 mm |
| Length (in.) | 175.59 in. |
| Width | 1825 mm |
| Width (in.) | 71.85 in. |
| Height | 1620 mm |
| Height (in.) | 63.78 in. |
| Wheelbase | 2640 mm |
| Wheelbase (in.) | 103.94 in. |
| Front track | 1569 mm |
| Front track (in.) | 61.77 in. |
| Rear track | 1581 mm |
| Rear track (in.) | 62.24 in. |
| Ride height (ground clearance) | 161 mm |
| Ride height (in.) | 6.34 in. |
| Minimum turning circle | 10.4 m |
| Minimum turning circle (ft.) | 34.12 ft. |
| Drivetrain Architecture | Front wheel drive |
| Number of gears | 7 |
| Gearbox type | automatic transmission CVT-i |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Torsion |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/60 R17 |
| Wheel rims size | 17 |
Powertrain & Engine Architecture
The heart of the Corolla Cross 1.8 Sport is the 2ZR-FAE 1.8-liter inline-four cylinder engine. This engine is a member of Toyota’s ZR engine family, known for its reliability and fuel efficiency. The 2ZR-FAE utilizes a multi-port fuel injection system and a double overhead camshaft (DOHC) valvetrain with four valves per cylinder. This configuration contributes to a reasonable balance of power and efficiency. The engine produces 140 horsepower at 6000 rpm and 177 Nm (130.55 lb.-ft.) of torque at 4000 rpm. Paired with this engine is Toyota’s CVT-i (Continuously Variable Transmission with intelligence) automatic transmission. This transmission features seven simulated gear ratios to provide a more natural driving feel compared to traditional CVTs. The CVT-i is designed to optimize fuel economy and provide smooth acceleration.
Driving Characteristics
The 1.8L engine and CVT-i combination in the Corolla Cross Sport delivers adequate performance for everyday driving. Acceleration is smooth and linear, but not particularly brisk. The CVT effectively keeps the engine in its optimal power band, providing sufficient power for merging onto highways and navigating city streets. Compared to potential higher-output engine options (which weren’t widely available in all markets for the Corolla Cross), the 1.8L feels less powerful, especially when fully loaded with passengers and cargo. The CVT, while efficient, lacks the responsiveness of a traditional automatic transmission or a manual gearbox. The gear ratios are tuned for fuel economy, prioritizing efficiency over outright performance. The steering is light and easy, making it well-suited for urban environments.
Equipment & Trim Levels
The Corolla Cross 1.8 Sport trim typically included features such as alloy wheels, a touchscreen infotainment system with smartphone integration (Apple CarPlay and Android Auto), automatic climate control, and a rearview camera. Safety features like ABS, electronic stability control, and multiple airbags were standard. Optional extras often included a sunroof, upgraded audio system, and advanced driver-assistance systems (ADAS) like adaptive cruise control and lane departure warning, depending on the specific market. Interior upholstery was typically cloth, with a focus on durability and practicality. The dashboard layout was functional and user-friendly, with a clear instrument cluster and logically arranged controls.
Chassis & Braking
The Corolla Cross utilizes a front-wheel-drive platform with an independent McPherson strut suspension in the front and a torsion beam suspension in the rear. This suspension setup provides a comfortable ride quality, absorbing bumps and imperfections in the road effectively. The front brakes are ventilated discs, providing adequate stopping power, while the rear brakes are solid discs. The electric power steering system offers light and precise steering feel. The vehicle’s ride height of 161 mm (6.34 inches) provides reasonable ground clearance for navigating various road conditions.
Market Reception & Comparison
The Corolla Cross 1.8 Sport was generally well-received by critics as a practical and fuel-efficient compact SUV. Reviewers praised its comfortable ride, spacious interior, and user-friendly technology. However, some criticized its lack of outright performance and the somewhat uninspiring driving experience offered by the CVT transmission. Compared to other trims in the Corolla Cross lineup, the 1.8 Sport offered a good balance of value and features. It was more affordable than higher-spec models but offered more equipment and a slightly more engaging driving experience than the base trims. Fuel economy was a strong point, with the 1.8L engine achieving competitive MPG figures.
Legacy
The Toyota Corolla Cross 1.8 Sport has proven to be a reliable and durable vehicle, benefiting from Toyota’s reputation for quality and dependability. The 2ZR-FAE engine is known for its longevity, and the CVT-i transmission, while not universally loved, has generally proven to be reliable with proper maintenance. In the used car market, the Corolla Cross 1.8 Sport represents a good value proposition for buyers seeking a practical, fuel-efficient, and affordable compact SUV. Its relatively simple mechanical design and readily available parts contribute to lower maintenance costs, making it an attractive option for budget-conscious buyers.
