The Toyota Crown XI Wagon (S170) 3.0i 24V, produced between 1999 and 2001, represented a sophisticated evolution of Toyota’s flagship sedan line. This variant, a station wagon (estate) body style, was primarily aimed at the Japanese domestic market (JDM) where larger, comfortable wagons remained popular. It occupied a premium position within the S170 Crown lineup, offering a blend of luxury, performance, and practicality. The S170 generation, built on the 1HX0 platform, sought to modernize the Crown while retaining its reputation for reliability and refinement. This 3.0i model, with its 220 horsepower engine and automatic transmission, was positioned above the more economical 2.5L and 2.0L variants, appealing to buyers seeking a more spirited driving experience.
Technical Specifications
| Brand | Toyota |
| Model | Crown |
| Generation | Crown XI Wagon (S170) |
| Type (Engine) | 3.0i 24V (220 Hp) Automatic |
| Start of production | 1999 |
| End of production | 2001 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate) |
| Seats | 5 |
| Doors | 5 |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 7.5 kg/Hp, 132.5 Hp/tonne |
| Weight-to-torque ratio | 5.6 kg/Nm, 177.1 Nm/tonne |
| Power | 220 Hp @ 5600 rpm |
| Power per litre | 73.4 Hp/l |
| Torque | 294 Nm @ 3600 rpm, 216.84 lb.-ft. @ 3600 rpm |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | 2JZ-FSE |
| Engine displacement | 2997 cm3, 182.89 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | Inline |
| Cylinder Bore | 86 mm, 3.39 in. |
| Piston Stroke | 86 mm, 3.39 in. |
| Compression ratio | 10.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 5.4 l, 5.71 US qt | 4.75 UK qt |
| Coolant | 7.5 l, 7.93 US qt | 6.6 UK qt |
| Kerb Weight | 1660 kg, 3659.67 lbs |
| Max. weight | 1935 kg, 4265.94 lbs |
| Max load | 275 kg, 606.27 lbs |
| Fuel tank capacity | 70 l, 18.49 US gal | 15.4 UK gal |
| Length | 4835 mm, 190.35 in |
| Width | 1765 mm, 69.49 in |
| Height | 1510 mm, 59.45 in |
| Wheelbase | 2780 mm, 109.45 in |
| Front track | 1495 mm, 58.86 in |
| Rear (Back) track | 1475 mm, 58.07 in |
| Ride height (ground clearance) | 155 mm, 6.1 in |
| Minimum turning circle (turning diameter) | 10.6 m, 34.78 ft |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 5 gears, automatic transmission |
| Front suspension | Double wishbone |
| Rear suspension | Double wishbone |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Tires size | 215/55 R16 |
| Wheel rims size | 6.5J x 16 |
Powertrain & Engine Architecture
The heart of the Crown XI Wagon 3.0i was the 2JZ-FSE engine, a 3.0-liter inline-six cylinder powerplant. This engine was a member of the renowned JZ series, known for its durability and potential for modification. The “FSE” designation indicated a fuel-stratified direct injection system, a relatively advanced technology for its time. This system aimed to improve fuel efficiency and reduce emissions by injecting fuel directly into the cylinder, creating a stratified charge – a richer mixture near the spark plug and a leaner mixture elsewhere. The engine featured a double overhead camshaft (DOHC) valvetrain, four valves per cylinder, and a compression ratio of 10.5:1. The 2JZ-FSE produced 220 horsepower at 5600 rpm and 294 Nm (216.84 lb-ft) of torque at 3600 rpm. The engine was longitudinally mounted, driving the rear wheels. The transmission was a 5-speed automatic, chosen for its smooth operation and suitability for the Crown’s luxury-oriented character. While not a particularly sporty transmission, it was well-matched to the engine’s torque curve.
Driving Characteristics
The 3.0i automatic Crown Wagon offered a comfortable and refined driving experience. The automatic transmission, while not offering manual control, provided smooth and predictable shifts. Acceleration was brisk, though not overtly sporty, with the 220 hp engine providing ample power for highway cruising and overtaking. The rear-wheel-drive configuration contributed to a balanced feel, although it wasn’t designed for aggressive cornering. Compared to the 2.5L and 2.0L models, the 3.0i offered noticeably more power and torque, resulting in a more relaxed driving experience, especially when fully loaded. The automatic transmission did slightly diminish the overall performance compared to a manual transmission equipped model, but the convenience and ease of use were prioritized for this trim level.
Equipment & Trim Levels
The Crown XI Wagon 3.0i typically came well-equipped, reflecting its position as a premium variant. Standard features often included power windows, power locks, power mirrors, air conditioning, a high-quality audio system, and comfortable cloth or leather upholstery. Higher trim levels within the 3.0i range could add features like a sunroof, navigation system, upgraded sound system, and woodgrain interior trim. The interior design emphasized comfort and spaciousness, with ample legroom for both front and rear passengers. The wagon body style provided a generous cargo area, making it a practical choice for families.
Chassis & Braking
The Crown XI Wagon utilized a double wishbone suspension setup at both the front and rear, providing a comfortable ride and reasonable handling. The suspension was tuned for comfort rather than outright sportiness. Braking duties were handled by ventilated discs at the front and solid discs at the rear. The braking system was adequate for the vehicle’s weight and performance, but not particularly powerful by modern standards. The tires were typically 215/55 R16, providing a good balance of comfort and grip.
Market Reception & Comparison
The Crown XI Wagon 3.0i was generally well-received in the Japanese market. Critics praised its comfortable ride, spacious interior, and refined engine. However, some noted that the automatic transmission could feel somewhat sluggish compared to manual options. Compared to other large wagons available in Japan at the time, the Crown offered a compelling combination of luxury, reliability, and practicality. The 3.0i variant was often seen as a more desirable option than the lower-powered models, offering a more satisfying driving experience. Fuel economy was reasonable for a vehicle of its size and engine displacement, but not exceptional.
Legacy
The Toyota Crown XI Wagon 3.0i 24V has developed a following among enthusiasts, particularly in Japan and increasingly in other markets as JDM cars gain popularity. The 2JZ-FSE engine is known for its durability and potential for modification, making it a popular choice for engine swaps and performance upgrades. While the direct injection system can require specialized maintenance, the engine is generally considered reliable if properly cared for. Today, well-maintained examples of the Crown XI Wagon 3.0i are sought after by collectors and enthusiasts who appreciate its unique blend of luxury, performance, and practicality. The car represents a high point in Toyota’s long history of producing comfortable and reliable vehicles.
