The Toyota Crown XIV Athlete (S210) 2.5 V6 24V, produced between 2012 and 2015, represented a significant iteration of Toyota’s flagship sedan. Positioned as a more sporty and luxurious variant within the broader S210 Crown lineup, the Athlete model aimed to attract buyers seeking a blend of performance and comfort. This particular configuration, featuring a 2.5-liter V6 engine paired with a six-speed automatic transmission, was primarily marketed in Japan, where the Crown held a prestigious position as a symbol of success and refinement. It served as a step up from the more economical Crown models, offering a more powerful and engaging driving experience, while remaining below the ultra-luxury trims.
Technical Specifications
| Brand | Toyota |
| Model | Crown |
| Generation | Crown XIV Athlete (S210) |
| Type (Engine) | 2.5 V6 24V (203 Hp) Automatic |
| Start of production | 2012 |
| End of production | 2015 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 7.7 kg/Hp, 129.3 Hp/tonne |
| Weight-to-torque ratio | 6.5 kg/Nm, 154.8 Nm/tonne |
| Power | 203 Hp @ 6400 rpm |
| Power per litre | 81.2 Hp/l |
| Torque | 243 Nm @ 4800 rpm, 179.23 lb.-ft. @ 4800 rpm |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | 4GR-FSE |
| Engine displacement | 2499 cm3, 152.5 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 83 mm, 3.27 in. |
| Piston Stroke | 77 mm, 3.03 in. |
| Compression ratio | 12:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 6.3 l, 6.66 US qt | 5.54 UK qt |
| Coolant | 9.1 l, 9.62 US qt | 8.01 UK qt |
| Kerb Weight | 1570 kg, 3461.26 lbs |
| Max. weight | 1840 kg, 4056.51 lbs |
| Max load | 270 kg, 595.25 lbs |
| Fuel tank capacity | 71 l, 18.76 US gal | 15.62 UK gal |
| Length | 4895 mm, 192.72 in |
| Width | 1800 mm, 70.87 in |
| Height | 1450 mm, 57.09 in |
| Wheelbase | 2850 mm, 112.2 in |
| Front track | 1545 mm, 60.83 in |
| Rear (Back) track | 1545 mm, 60.83 in |
| Ride height (ground clearance) | 135 mm, 5.31 in |
| Minimum turning circle (turning diameter) | 10.4 m, 34.12 ft |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 6 gears, automatic transmission |
| Front suspension | Double wishbone |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 215/55 R17 |
| Wheel rims size | 17 |
Powertrain & Engine Architecture
The heart of the Crown Athlete 2.5 V6 was the 4GR-FSE engine, a 2.5-liter naturally aspirated V6. This engine utilized Toyota’s D-4S direct injection system, combining direct and port injection to optimize combustion efficiency and power delivery. The DOHC (Double Overhead Camshaft) valvetrain, with four valves per cylinder, further enhanced breathing and contributed to the engine’s respectable output. The 4GR-FSE was known for its smooth operation and relatively high revving nature for a V6 of its displacement. Paired with this engine was a six-speed automatic transmission, designed to provide smooth and responsive shifts. This transmission wasn’t a particularly advanced unit by contemporary standards, but it was reliable and well-suited to the engine’s power characteristics. The longitudinal engine layout and rear-wheel drive configuration were traditional for the Crown, emphasizing driving dynamics.
Driving Characteristics
The 203 horsepower and 243 Nm (179 lb-ft) of torque delivered by the 2.5 V6 and automatic transmission combination provided a comfortable and capable driving experience. While not overtly sporty, the Athlete model offered noticeably more responsive acceleration than the base Crown variants. The automatic transmission, while smooth, wasn’t particularly quick to downshift, meaning that overtaking maneuvers required a degree of planning. Compared to the manual transmission options available on other Crown models, the automatic felt less engaging, but it prioritized ease of use and comfort. The rear-wheel drive layout contributed to balanced handling, although the relatively soft suspension tuning prioritized ride quality over sharp cornering.
Equipment & Trim Levels
The Crown Athlete 2.5 V6 typically came well-equipped, reflecting its position as a premium trim level. Standard features often included leather upholstery, power-adjustable front seats, a multi-function steering wheel, automatic climate control, and a high-quality audio system. Optional extras could include navigation systems, premium sound upgrades, and advanced safety features like adaptive cruise control and lane departure warning. The interior design was generally conservative and elegant, emphasizing comfort and refinement. The Athlete trim often featured unique exterior styling cues, such as a more aggressive front bumper, side skirts, and a rear spoiler, to differentiate it from other Crown models.
Chassis & Braking
The Crown Athlete 2.5 V6 utilized a double wishbone suspension setup at the front and an independent multi-link suspension at the rear, providing a comfortable and controlled ride. The suspension was tuned for a balance between comfort and handling, leaning more towards the former. Braking duties were handled by ventilated discs at the front and solid discs at the rear, equipped with an Anti-lock Braking System (ABS) as standard. The braking performance was adequate for the vehicle’s weight and power, but not particularly outstanding. The steering system employed a rack and pinion setup, providing reasonably precise steering feel.
Market Reception & Comparison
The Crown Athlete 2.5 V6 was generally well-received in the Japanese market. Critics praised its comfortable ride, refined interior, and smooth engine. However, some noted that the automatic transmission could feel a bit sluggish, and the handling wasn’t as sharp as some of its competitors. Compared to the more fuel-efficient Crown models with smaller engines, the 2.5 V6 offered a more rewarding driving experience, but at the cost of increased fuel consumption. Against other luxury sedans in its class, the Crown Athlete offered a compelling value proposition, combining Toyota’s renowned reliability with a generous level of equipment.
Legacy
The Toyota Crown XIV Athlete (S210) 2.5 V6 24V has proven to be a reliable and durable vehicle. The 4GR-FSE engine is known for its longevity, and the six-speed automatic transmission is generally trouble-free. In the used car market, these Crowns are often sought after for their combination of comfort, reliability, and relatively affordable price. While not a performance icon, the Athlete 2.5 V6 represents a well-engineered and thoughtfully designed luxury sedan that continues to provide comfortable and dependable transportation for its owners. Its enduring appeal is a testament to Toyota’s commitment to quality and refinement.
