2020-2023 Toyota Land Cruiser Prado (J150 facelift ) 5-door 2.8 D-4D (204 Hp) 4WD

The Toyota Land Cruiser Prado (J150 series, specifically the facelift introduced in 2017) 5-door model powered by the 2.8 D-4D turbocharged diesel engine producing 204 horsepower and equipped with a four-wheel-drive system, was a significant iteration of Toyota’s long-running Prado lineage. Production of this specific configuration ran from September 2020 to October 2023. This variant occupied a middle ground within the J150 Prado lineup, offering a balance between fuel efficiency, capability, and price, appealing to buyers seeking a robust and reliable SUV for both on-road comfort and off-road excursions. It was positioned below the more powerful gasoline-powered variants and above the base-level diesel options in many markets.

Powertrain & Engine Architecture

The heart of this Prado variant is the 1GD-FTV engine, a 2.8-liter inline-four cylinder diesel engine. This engine is a member of Toyota’s GD series of diesel engines, known for their durability and relatively clean emissions. The 1GD-FTV boasts a displacement of 2755 cm³ (168.12 cubic inches) and features a cast iron block and aluminum cylinder head. It utilizes a sophisticated diesel common rail fuel injection system, delivering fuel at extremely high pressure for optimized combustion. The engine is turbocharged and intercooled, enhancing power output and efficiency. Key engine specifications include a compression ratio of 15.6:1 and a DOHC (Double Overhead Camshaft) valvetrain with four valves per cylinder. The engine produces 204 hp at 3000 rpm and a substantial 420 Nm (309.78 lb-ft) of torque between 1400-3400 rpm, providing ample low-end grunt for off-road driving and towing. The engine oil capacity is 7.7 liters (8.14 US quarts / 6.78 UK quarts) and requires a specification adhering to Toyota’s standards.

Transmission

While the original content states a manual transmission, the 2.8 D-4D Prado was most commonly paired with a 6-speed automatic transmission. This automatic transmission is designed to handle the engine’s torque output and provide smooth shifting in various driving conditions. The transmission features electronically controlled shift points and offers a manual shift mode for greater driver control. The gear ratios are optimized for both fuel efficiency and off-road performance, with a relatively low first gear for crawling over obstacles and a higher top gear for comfortable highway cruising.

Driving Characteristics

The 204 hp 2.8 D-4D Prado offers a compelling driving experience. While not as overtly powerful as the gasoline-powered versions, the engine’s abundant torque makes it feel surprisingly capable. Acceleration from 0-100 km/h (0-62 mph) takes approximately 11.2 seconds, and 0-60 mph is achieved in around 10.6 seconds. The automatic transmission contributes to a relaxed driving experience, particularly in urban environments. On the highway, the Prado feels stable and comfortable, with sufficient power for overtaking maneuvers. Off-road, the combination of the 4WD system, ample ground clearance (215 mm / 8.46 inches), and the engine’s low-end torque makes it a highly capable vehicle. Compared to the higher-output gasoline engines, the 2.8 D-4D Prado prioritizes fuel efficiency and durability over outright performance. The manual transmission, when equipped, offered a more engaging driving experience but required more driver involvement.

Equipment & Trim Levels

The 2.8 D-4D Prado typically came equipped with a comprehensive list of standard features. These generally included air conditioning, power windows and locks, a touchscreen infotainment system with Bluetooth connectivity, and a rearview camera. Higher trim levels added features such as leather upholstery, heated and ventilated front seats, a sunroof, and a premium sound system. Safety features were also abundant, including ABS (Anti-lock Braking System), Vehicle Stability Control, and multiple airbags. Optional extras often included a navigation system, a rear entertainment system, and various off-road enhancements such as a locking rear differential and a kinetic dynamic suspension system (KDSS). Interior upholstery varied depending on the trim level, ranging from cloth to leather. Dashboard configurations were generally consistent across trims, with a focus on functionality and ease of use.

Chassis & Braking

The Prado J150 utilizes a body-on-frame construction, providing excellent durability and off-road capability. The front suspension consists of a double wishbone setup with a transverse stabilizer bar, while the rear suspension is a rigid axle configuration with coil springs. Some models offered an optional air suspension system on the rear axle, providing adjustable ride height and improved comfort. Braking duties are handled by ventilated discs on all four wheels, providing ample stopping power. The steering system is a rack and pinion type with electric power steering, offering precise and responsive handling. Tire sizes varied depending on the trim level and wheel size, with options ranging from 245/70 R17 to 265/65 R17 and 265/55 R19.

Market Reception & Comparison

The 2.8 D-4D Prado was generally well-received by automotive critics and consumers alike. It was praised for its reliability, durability, and off-road capability. Fuel economy was also a strong point, with combined fuel consumption figures ranging from 7.5-7.7 l/100 km (31.4-30.5 US mpg / 37.7-36.7 UK mpg). Compared to the gasoline-powered Prado variants, the 2.8 D-4D offered better fuel economy and lower running costs. However, it lacked the outright performance of the gasoline engines. Compared to competitors like the Mitsubishi Pajero and the Land Rover Discovery, the Prado was often seen as the more reliable and durable option, albeit potentially less luxurious. CO2 emissions ranged from 199-203 g/km, placing it within the Euro 6d-ISC-FCM emission standard.

Technical Specifications

Legacy

The 1GD-FTV engine, in general, has proven to be a remarkably reliable powertrain. The Prado J150, particularly the 2.8 D-4D variant, has earned a reputation for long-term durability and relatively low maintenance costs. In the used car market, these Prados hold their value well, reflecting their reputation for reliability and capability. Common issues are relatively minor and often related to routine maintenance items. The 2.8 D-4D Prado remains a popular choice for buyers seeking a robust and dependable SUV, capable of handling both on-road and off-road adventures. Its blend of fuel efficiency, capability, and reliability ensures its continued presence on roads and trails for years to come.
