The Volkswagen Golf I (3-door) 1.5 Automatic, produced between 1977 and 1983, represented an accessible entry point into the first generation Golf range. Positioned as a more economical and comfort-oriented option, it catered to buyers prioritizing ease of use over outright performance. This variant utilized Volkswagen’s FH or FD engine code, and was a significant part of the Golf’s initial success, particularly in European markets where automatic transmissions were less common but gaining popularity. It was built on the 1HX0 platform, the foundation for the entire Mk1 Golf lineup.
Technical Specifications
| Brand | Volkswagen |
| Model | Golf |
| Generation | Golf I (3-door) |
| Type (Engine) | 1.5 (70 Hp) Automatic |
| Start of production | 1977 |
| End of production | 1983 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 3 |
| Fuel consumption (urban) | 10.1 l/100 km (23.3 US mpg, 28 UK mpg, 9.9 km/l) |
| Fuel consumption (extra urban) | 7.3 l/100 km (32.2 US mpg, 38.7 UK mpg, 13.7 km/l) |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 60 mph | 14.7 sec |
| Maximum speed | 153 km/h (95.07 mph) |
| Weight-to-power ratio | 11.9 kg/Hp, 84.3 Hp/tonne |
| Weight-to-torque ratio | 7.5 kg/Nm, 132.5 Nm/tonne |
| Power | 70 Hp @ 5600 rpm |
| Power per litre | 48 Hp/l |
| Torque | 110 Nm @ 2500 rpm (81.13 lb.-ft. @ 2500 rpm) |
| Engine layout | Front, Transverse |
| Engine Model/Code | FH, FD |
| Engine displacement | 1457 cm3 (88.91 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 79.5 mm (3.13 in.) |
| Piston Stroke | 73.4 mm (2.89 in.) |
| Compression ratio | 8.2:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Carburettor |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | SOHC |
| Engine oil capacity | 3.5 l (3.7 US qt | 3.08 UK qt) |
| Coolant | 4.5 l (4.76 US qt | 3.96 UK qt) |
| Kerb Weight | 830 kg (1829.84 lbs.) |
| Max. weight | 1250 kg (2755.78 lbs.) |
| Max load | 420 kg (925.94 lbs.) |
| Trunk (boot) space – minimum | 368 l (13 cu. ft.) |
| Trunk (boot) space – maximum | 1102 l (38.92 cu. ft.) |
| Fuel tank capacity | 40 l (10.57 US gal | 8.8 UK gal) |
| Permitted trailer load with brakes (12%) | 1000 kg (2204.62 lbs.) |
| Permitted trailer load without brakes | 400 kg (881.85 lbs.) |
| Length | 3723 mm (146.57 in.) |
| Width | 1610 mm (63.39 in.) |
| Height | 1410 mm (55.51 in.) |
| Wheelbase | 2400 mm (94.49 in.) |
| Front track | 1389 mm (54.69 in.) |
| Rear (Back) track | 1356 mm (53.39 in.) |
| Ride height (ground clearance) | 125 mm (4.92 in.) |
| Minimum turning circle (turning diameter) | 10.5 m (34.45 ft.) |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 3 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Trailing arm, Coil spring, Torsion |
| Front brakes | Disc, 238.76 mm |
| Rear brakes | Drum, 180.34 mm |
| Steering type | Steering rack and pinion |
| Tires size | 175/70 R13 |
| Wheel rims size | 5J x 13 |
Powertrain & Engine Architecture
The heart of the Golf I 1.5 Automatic was the 1457cc inline-four cylinder engine, designated either FH or FD depending on minor variations. This engine featured a single overhead camshaft (SOHC) valvetrain with two valves per cylinder. Fuel delivery was managed by a Solex or Pierburg carburetor, a common setup for the era, prioritizing simplicity and cost-effectiveness over the precision of fuel injection. The engine produced 70 horsepower at 5600 rpm and 110 Nm (81.13 lb-ft) of torque at 2500 rpm. The automatic transmission was a three-speed unit, offering a smoother driving experience than the available four-speed manual, but at the expense of performance and fuel economy. This transmission was designed for durability and ease of maintenance, typical of automatic gearboxes of the 1970s.
Driving Characteristics
The 1.5 Automatic Golf offered a relaxed and comfortable driving experience. Acceleration was modest, taking approximately 14.7 seconds to reach 60 mph, and the top speed was around 95 mph. The three-speed automatic transmission, while providing convenience, resulted in noticeable gear changes and a less engaging driving feel compared to the manual versions. The gear ratios were optimized for fuel efficiency and everyday usability rather than spirited driving. Compared to the more powerful Golf variants, such as those equipped with the 1.6 or 1.8 engines, the 1.5 Automatic felt noticeably slower, particularly when overtaking or climbing hills. However, its smooth operation and ease of use made it a popular choice for urban commuting and drivers less concerned with outright performance.
Equipment & Trim Levels
The 1.5 Automatic typically came with a relatively basic level of equipment, reflecting its position as an entry-level model. Standard features included cloth upholstery, basic instrumentation, and a two-spoke steering wheel. Optional extras included a sunroof, upgraded stereo systems, and more comfortable seating. The interior trim was generally functional and durable, prioritizing practicality over luxury. The Golf I offered a degree of customization, allowing buyers to add features based on their budget and preferences. The base trim level focused on providing essential transportation, while optional packages could enhance comfort and convenience.
Chassis & Braking
The Golf I 1.5 Automatic utilized a McPherson strut front suspension with coil springs and an anti-roll bar, providing a reasonable level of handling and ride comfort. The rear suspension employed a trailing arm setup with coil springs and a torsion beam. Braking was accomplished via disc brakes on the front wheels and drum brakes on the rear. This configuration was typical for cars in this class during the late 1970s and early 1980s. The braking system was adequate for everyday driving, but lacked the stopping power of more modern systems. The chassis was designed to provide a balance between comfort and handling, making the Golf I a relatively enjoyable car to drive on a variety of road surfaces.
Market Reception & Comparison
The Golf I 1.5 Automatic was generally well-received as a practical and affordable family car. Critics praised its comfortable ride, spacious interior, and ease of use. However, the automatic transmission and relatively low power output were often criticized. Compared to the manual versions, the 1.5 Automatic offered less driver engagement and slightly worse fuel economy. Against competitors like the Ford Escort and Opel Kadett, the Golf I offered a more refined driving experience and a reputation for reliability. The 1.5 Automatic appealed to buyers who prioritized convenience and comfort over performance, making it a popular choice for families and less experienced drivers.
Legacy
The Volkswagen Golf I 1.5 Automatic, while not the most powerful or sporty variant, played a crucial role in establishing the Golf as a successful and versatile family car. The FH and FD engines, while simple in design, proved to be relatively reliable and easy to maintain. Today, well-maintained examples are sought after by classic car enthusiasts. The three-speed automatic transmission, while dated by modern standards, is generally durable and can provide years of reliable service with proper maintenance. The Golf I 1.5 Automatic represents a significant chapter in Volkswagen’s history and remains a popular choice for those seeking a classic and affordable hatchback.
