The Volkswagen Polo Vivo I Sedan 1.4 (86 hp) was a key model in Volkswagen’s lineup, specifically designed for markets like South Africa and other regions where affordability and practicality were paramount. Produced from 2010 to 2017, this variant represented an entry point into the Polo range, offering a balance between fuel efficiency and basic transportation. It was built on the older Polo platform (9N3), continuing production after the newer Polo (6R) was introduced elsewhere, providing a cost-effective option for buyers. This sedan version aimed to cater to families and individuals needing a spacious and reliable vehicle at a competitive price point.
Technical Specifications
| Brand | Volkswagen |
| Model | Polo Vivo |
| Generation | Polo Vivo I Sedan |
| Type (Engine) | 1.4 (86 Hp) |
| Start of production | 2010 |
| End of production | 2017 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Fuel consumption (urban) | 8.1 l/100 km (29 US mpg, 34.9 UK mpg, 12.3 km/l) |
| Fuel consumption (extra urban) | 5.1 l/100 km (46.1 US mpg, 55.4 UK mpg, 19.6 km/l) |
| Fuel consumption (combined) | 6.2 l/100 km (37.9 US mpg, 45.6 UK mpg, 16.1 km/l) |
| CO2 emissions | 147 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 12.2 sec |
| Acceleration 0 – 62 mph | 12.2 sec |
| Acceleration 0 – 60 mph | 11.6 sec |
| Maximum speed | 177 km/h (109.98 mph) |
| Weight-to-power ratio | 12.6 kg/Hp, 79.3 Hp/tonne |
| Weight-to-torque ratio | 8.2 kg/Nm, 121.7 Nm/tonne |
| Power | 86 Hp @ 5000 rpm |
| Power per litre | 61.5 Hp/l |
| Torque | 132 Nm @ 3600 rpm (97.36 lb.-ft. @ 3600 rpm) |
| Engine layout | Front, Transverse |
| Engine Model/Code | CLPA |
| Engine displacement | 1398 cm3 (85.31 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 76.5 mm (3.01 in.) |
| Piston Stroke | 75.6 mm (2.98 in.) |
| Compression ratio | 10.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 3.2 l (3.38 US qt | 2.82 UK qt) |
| Kerb Weight | 1085 kg (2392.02 lbs.) |
| Trunk (boot) space – minimum | 432 l (15.26 cu. ft.) |
| Trunk (boot) space – maximum | 737 l (26.03 cu. ft.) |
| Fuel tank capacity | 45 l (11.89 US gal | 9.9 UK gal) |
| Length | 4198 mm (165.28 in.) |
| Width | 1650 mm (64.96 in.) |
| Height | 1467 mm (57.76 in.) |
| Wheelbase | 2462 mm (96.93 in.) |
| Front track | 1434 mm (56.46 in.) |
| Rear (Back) track | 1426 mm (56.14 in.) |
| Ride height (ground clearance) | 115 mm (4.53 in.) |
| Minimum turning circle | 10.6 m (34.78 ft.) |
| Drivetrain Architecture | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Spring Strut, Wishbone, Transverse stabilizer |
| Rear suspension | Spring Strut, Trailing arm, Torsion |
| Front brakes | Disc |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 175/65 R14 |
| Wheel rims size | 5J x 14 |
Powertrain & Engine Architecture
The Polo Vivo 1.4 utilized the CLPA engine code, a 1.4-liter inline-four cylinder petrol engine. This engine was a relatively simple design, employing a multi-point fuel injection system and a double overhead camshaft (DOHC) valvetrain. The CLPA engine was known for its robustness and relatively low maintenance requirements. It featured a compression ratio of 10.5:1, contributing to its modest power output. The 86 horsepower was achieved at 5000 rpm, while peak torque of 132 Nm (97.36 lb-ft) was delivered at 3600 rpm. The engine’s transverse mounting and front-wheel drive configuration were standard for this class of vehicle. The five-speed manual transmission was the standard offering, designed for durability and ease of use rather than sporty performance.
Driving Characteristics
The 1.4-liter engine with the five-speed manual transmission provided adequate, but not exhilarating, performance. Acceleration from 0 to 100 km/h (0-62 mph) took approximately 12.2 seconds, and the top speed was around 177 km/h (109.98 mph). The gear ratios were tuned for fuel efficiency and everyday drivability, rather than outright speed. Compared to potential higher-output versions (which weren’t commonly offered in this market segment for the Vivo), this variant felt noticeably less responsive. However, the lighter weight of the vehicle helped to mitigate some of the power deficit. The manual transmission offered a more engaging driving experience than an automatic would have, allowing drivers to better control the engine’s power band.
Equipment & Trim Levels
The Polo Vivo 1.4 Sedan was typically offered as a base trim level. Standard equipment generally included power steering, central locking, and an immobilizer. Air conditioning was often an optional extra. Interior upholstery was typically cloth, and the dashboard featured a functional, if somewhat basic, design. Optional extras could include power windows, a radio/CD player, and alloy wheels. The focus was on providing essential features at an affordable price point, rather than luxury or advanced technology.
Chassis & Braking
The Polo Vivo 1.4 Sedan utilized a MacPherson strut front suspension and a torsion beam rear suspension. This setup provided a reasonable balance between ride comfort and handling. The front brakes were disc brakes, while the rear brakes were drum brakes – a cost-saving measure common in this segment. ABS (Anti-lock Braking System) was standard, enhancing safety. The relatively lightweight nature of the vehicle contributed to its manageable handling characteristics. Stabilizer bars were included to reduce body roll during cornering.
Market Reception & Comparison
The Polo Vivo 1.4 Sedan was well-received in its target markets as a practical and affordable family car. Critics generally praised its reliability and fuel efficiency. Compared to other vehicles in its class, the Vivo offered a good level of space and practicality for its price. Fuel economy figures of around 6.2 l/100 km (37.9 US mpg) were competitive. While not the most powerful or luxurious option, it represented a sensible choice for budget-conscious buyers. Compared to potential higher-trim Polo models, the 1.4 offered a significantly lower price point, but at the expense of performance and features.
Legacy
The Volkswagen Polo Vivo 1.4 Sedan has proven to be a durable and reliable vehicle. In the used car market, these models are often sought after for their affordability and low running costs. The CLPA engine is known for its longevity, and parts availability is generally good. While not a performance icon, the Polo Vivo 1.4 Sedan played an important role in providing accessible transportation to a wide range of buyers, and continues to be a viable option for those seeking a dependable and economical used car.
