The Volkswagen Tiguan II Allspace 2.0 BiTDI (240 Hp) 4MOTION DSG is a compact SUV produced by the German manufacturer Volkswagen between October 2016 and August 2018. This model represents an extended-wheelbase version of the second-generation Tiguan (Tiguan II), offering optional seven-passenger seating. Primarily marketed in Europe, the Allspace aimed to provide a more spacious alternative within the popular compact SUV segment, competing with vehicles like the Nissan X-Trail and Hyundai Santa Fe. The “Allspace” designation highlights the increased interior volume and practicality compared to the standard Tiguan II.
Volkswagen Tiguan II Allspace: An Overview
The Tiguan II Allspace was designed to cater to families needing more space without opting for a larger, more expensive SUV. It builds upon the successful foundation of the Tiguan II, incorporating a longer wheelbase and a redesigned rear section to accommodate the optional third-row seats. The 2.0 BiTDI variant, equipped with a powerful biturbo diesel engine and Volkswagen’s 4MOTION all-wheel-drive system, offered a compelling combination of performance, efficiency, and practicality for European drivers.
Engine & Performance
The heart of the Tiguan II Allspace 2.0 BiTDI is a 2.0-liter inline-four cylinder diesel engine, designated CUAA. This engine utilizes a sophisticated biturbocharger system – two turbochargers working in sequence – to deliver a substantial 240 horsepower at 4000 rpm and 500 Nm (368.78 lb.-ft.) of torque between 1750 and 2500 rpm. This configuration provides strong acceleration and ample power for both highway cruising and everyday driving. The engine features direct injection with a common rail system, ensuring precise fuel delivery and optimized combustion. Acceleration from 0 to 100 km/h (0-62 mph) takes 6.5 seconds, while 0-60 mph is achieved in approximately 6.2 seconds. The vehicle boasts a maximum speed of 228 km/h (141.67 mph). The engine’s power-to-weight ratio is 7.7 kg/Hp, and its torque-to-weight ratio is 3.7 kg/Nm. The engine meets Euro 6 emission standards, incorporating a particulate filter and a Start & Stop system to enhance fuel efficiency and reduce emissions.
Design & Features
The Tiguan II Allspace maintains the contemporary SUV styling of the standard Tiguan II, but with a noticeably longer rear overhang. This extension provides the space for the optional third-row seating, increasing the vehicle’s overall length to 4701 mm (185.08 in). The body style is a five-door SUV, offering easy access to both front and rear seats. Key features include a spacious interior, a versatile cargo area, and a range of modern technology. With all seats in place, the trunk offers 230 liters (8.12 cu. ft.) of space, expanding to a substantial 1775 liters (62.68 cu. ft.) with the rear seats folded down. The vehicle’s interior is designed with practicality and comfort in mind, featuring high-quality materials and a user-friendly infotainment system. Safety features, typical of modern European vehicles, include ABS, electronic stability control, and multiple airbags. The 4MOTION all-wheel-drive system provides enhanced traction and stability in various driving conditions.
Technical Specifications
| Brand | Volkswagen |
| Model | Tiguan |
| Generation | Tiguan II Allspace |
| Type (Engine) | 2.0 BiTDI (240 Hp) 4MOTION DSG |
| Start of production | October, 2016 |
| End of production | August, 2018 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 7 |
| Doors | 5 |
| Fuel consumption (urban) | 7.4 l/100 km (31.8 US mpg) |
| Fuel consumption (extra urban) | 5.8 l/100 km (40.6 US mpg) |
| Fuel consumption (combined) | 6.4 l/100 km (36.8 US mpg) |
| CO2 emissions | 167 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 6.5 sec |
| Acceleration 0 – 62 mph | 6.5 sec |
| Acceleration 0 – 60 mph | 6.2 sec |
| Maximum speed | 228 km/h (141.67 mph) |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 7.7 kg/Hp |
| Weight-to-torque ratio | 3.7 kg/Nm |
| Power | 240 Hp @ 4000 rpm |
| Torque | 500 Nm @ 1750-2500 rpm (368.78 lb.-ft. @ 1750-2500 rpm) |
| Engine layout | Front, Transverse |
| Engine Model/Code | CUAA |
| Engine displacement | 1968 cm3 (120.09 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 81 mm (3.19 in.) |
| Piston Stroke | 95.5 mm (3.76 in.) |
| Compression ratio | 15.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | BiTurbo, Intercooler |
| Engine oil capacity | 4.9 l (5.18 US qt | 4.31 UK qt) |
| Kerb Weight | 1845 kg (4067.53 lbs.) |
| Max. weight | 2430 kg (5357.23 lbs.) |
| Max load | 585 kg (1289.7 lbs.) |
| Trunk (boot) space – minimum | 230 l (8.12 cu. ft.) |
| Trunk (boot) space – maximum | 1775 l (62.68 cu. ft.) |
| Fuel tank capacity | 60 l (15.85 US gal | 13.2 UK gal) |
| AdBlue tank | 12 l (3.17 US gal | 2.64 UK gal) |
| Max. roof load | 75 kg (165.35 lbs.) |
| Permitted trailer load with brakes (12%) | 2500 kg (5511.56 lbs.) |
| Permitted trailer load without brakes | 750 kg (1653.47 lbs.) |
| Permitted towbar download | 100 kg (220.46 lbs.) |
| Length | 4701 mm (185.08 in.) |
| Width | 1839 mm (72.4 in.) |
| Width including mirrors | 2099 mm (82.64 in.) |
| Height | 1674 mm (65.91 in.) |
| Wheelbase | 2787 mm (109.72 in.) |
| Ride height (ground clearance) | 201 mm (7.91 in.) |
| Minimum turning circle | 11.9 m (39.04 ft.) |
| Drive wheel | All wheel drive (4×4) |
| Number of gears | 7 |
| Type of gearbox | automatic transmission DSG |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Steering type | Steering rack and pinion |
| Tires size | 235/55 R18 |
The Volkswagen Tiguan II Allspace 2.0 BiTDI 4MOTION DSG offered a compelling package for European buyers seeking a spacious, efficient, and capable compact SUV. Its powerful engine, advanced all-wheel-drive system, and practical interior made it a popular choice in its segment.
