The Volvo EX30 51 kWh Single Motor, launched in June 2023, represents Volvo’s entry into the compact luxury electric SUV segment. Positioned as the most accessible model in Volvo’s all-electric lineup, the EX30 aims to broaden the brand’s appeal to a younger, more urban demographic. Built on a dedicated electric vehicle platform, it prioritizes sustainability, technology, and a streamlined driving experience. This variant, equipped with a 51 kWh battery and a single rear-mounted electric motor producing 272 horsepower, offers a balance between range, performance, and affordability within the EX30 range.
Technical Specifications
| Brand | Volvo |
| Model | EX30 |
| Generation | EX30 |
| Type (Engine) | 51 kWh (272 Hp) Single Motor |
| Start of production | June, 2023 |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Fuel Type | Electricity |
| Acceleration 0 – 100 km/h | 5.7 sec |
| Acceleration 0 – 62 mph | 5.7 sec |
| Acceleration 0 – 60 mph | 5.4 sec |
| Maximum speed | 180 km/h (111.85 mph) |
| Gross battery capacity | 51 kWh |
| Net (usable) battery capacity | 49 kWh |
| Battery technology | Lithium iron phosphate (LiFePO4) |
| Battery location | Below the floor |
| All-electric range (WLTP) | 344 km (213.75 mi) |
| All-electric range (EPA) | 321.9 km (200.02 mi) |
| Electric motor power | 272 Hp @ 5375-9248 rpm |
| Electric motor Torque | 343 Nm @ 116-5375 rpm (252.98 lb.-ft. @ 116-5375 rpm) |
| Electric motor location | Rear axle, Transverse |
| Electric motor type | Synchronous |
| System power | 272 Hp @ 5375-9248 rpm |
| System torque | 343 Nm @ 116-5375 rpm (252.98 lb.-ft. @ 116-5375 rpm) |
| Trunk (boot) space – minimum | 234 l (8.26 cu. ft.) |
| Trunk (boot) space – maximum | 904 l (31.92 cu. ft.) |
| Max. roof load | 75 kg (165.35 lbs.) |
| Permitted trailer load with brakes (12%) | 1000 kg (2204.62 lbs.) |
| Length | 4233 mm (166.65 in.) |
| Width | 1837 mm (72.32 in.) |
| Width with mirrors folded | 1940 mm (76.38 in.) |
| Width including mirrors | 2032 mm (80 in.) |
| Height | 1549 mm (60.98 in.) |
| Wheelbase | 2650 mm (104.33 in.) |
| Front track | 1590 mm (62.6 in.) |
| Rear (Back) track | 1595 mm (62.8 in.) |
| Front overhang | 788 mm (31.02 in.) |
| Rear overhang | 795 mm (31.3 in.) |
| Ride height (ground clearance) | 165 mm (6.5 in.) |
| Drag coefficient (Cd) | 0.28 |
| Minimum turning circle (turning diameter) | 11 m (36.09 ft.) |
| Approach angle | 17.9° |
| Departure angle | 24.5° |
| Ramp-over (brakeover) angle | 16.3° |
| Wading depth | 500 mm (19.69 in.) |
| Drivetrain Architecture | One electric motor drives the rear wheels. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Spring Strut, Independent type McPherson, Transverse stabilizer |
| Rear suspension | Spring Strut, Independent multi-link suspension, Transverse stabilizer |
| Front brakes | Ventilated discs, 322×28 mm |
| Rear brakes | Ventilated discs, 320×20 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
INTRODUCTION
The Volvo EX30 51 kWh Single Motor is a compact SUV that debuted in 2023 as Volvo’s smallest and most affordable electric vehicle. It’s built on Volvo’s next-generation Sustainable Mobility Technology (SMT) platform, designed specifically for electric vehicles. This platform allows for a streamlined manufacturing process and a focus on sustainable materials. The EX30 slots below the XC40 Recharge and C40 Recharge in Volvo’s electric lineup, targeting a different segment of the market with its lower price point and more compact dimensions. It’s intended to appeal to urban drivers and those new to the electric vehicle market.
Powertrain & Engine Architecture
The EX30 51 kWh utilizes a single permanent magnet synchronous electric motor driving the rear wheels. This motor produces 272 horsepower and 343 Nm (252.98 lb-ft) of torque. The 51 kWh lithium iron phosphate (LiFePO4) battery pack is positioned under the floor, contributing to a low center of gravity and improved handling. LiFePO4 chemistry is chosen for its enhanced thermal stability and longer lifespan compared to traditional nickel-manganese-cobalt (NMC) batteries, though it typically offers slightly lower energy density. The EX30 employs a single-speed automatic transmission, typical for electric vehicles, delivering instant torque and smooth acceleration. The car’s electrical architecture is designed for over-the-air (OTA) software updates, allowing for continuous improvement and the addition of new features.
Driving Characteristics
The EX30 51 kWh offers brisk acceleration, achieving 0-60 mph in approximately 5.4 seconds. While not as quick as the dual-motor variants, the single-motor setup provides ample power for everyday driving and highway merging. The rear-wheel-drive configuration contributes to a balanced feel, although it may require some adjustment for drivers accustomed to front-wheel-drive vehicles, particularly in slippery conditions. The single-speed transmission provides seamless acceleration, and the regenerative braking system allows for one-pedal driving, enhancing efficiency and convenience. Compared to higher-output EX30 models, this variant prioritizes efficiency over outright performance, offering a longer range for a given battery capacity.
Equipment & Trim Levels
The EX30 51 kWh comes standard with a minimalist and tech-focused interior. Standard features include a 12.3-inch touchscreen infotainment system powered by Google Automotive OS, offering integrated Google Assistant, Google Maps, and access to various apps. A digital instrument cluster provides essential driving information. The base trim typically includes automatic climate control, keyless entry, and a suite of advanced driver-assistance systems (ADAS) such as automatic emergency braking and lane-keeping assist. Interior upholstery is typically a mix of recycled materials and textiles. Optional extras include premium audio systems, panoramic sunroof, and upgraded interior trim packages.
Chassis & Braking
The EX30 features a McPherson strut front suspension and a multi-link rear suspension, both incorporating transverse stabilizer bars to minimize body roll. The suspension is tuned for a comfortable ride while maintaining responsive handling. Ventilated disc brakes are used on all four wheels, providing ample stopping power. The EX30 incorporates an anti-lock braking system (ABS) and electronic stability control (ESC) as standard safety features. The relatively low weight of the 51 kWh variant contributes to its agility and braking performance.
Market Reception & Comparison
The Volvo EX30 has been generally well-received by critics, praised for its stylish design, sustainable materials, and advanced technology. The 51 kWh Single Motor variant is often highlighted as the most practical choice for buyers prioritizing affordability and range. Compared to other compact electric SUVs like the Hyundai Kona Electric and the Chevrolet Bolt EUV, the EX30 offers a more premium interior and a stronger emphasis on Scandinavian design. However, some reviewers have noted the limited rear visibility due to the sloping roofline. Fuel economy, expressed as MPGe (miles per gallon equivalent), is competitive within its class, and the LiFePO4 battery is expected to offer good long-term durability.
Legacy
The Volvo EX30 represents a significant step for Volvo in expanding its electric vehicle offerings and reaching a wider audience. The use of the SMT platform and sustainable materials demonstrates Volvo’s commitment to environmental responsibility. The 51 kWh Single Motor variant is expected to be a popular choice in the used car market due to its affordability and practicality. The long-term reliability of the LiFePO4 battery and the electric powertrain remains to be seen, but Volvo’s reputation for safety and build quality suggests a positive outlook. The EX30’s success will likely influence Volvo’s future electric vehicle development and further accelerate the transition to a fully electric lineup.
